1
Engine displacement
autre
2
Year
2017
3
Trim
BRUTUS HD HDPTO (R01) - D17B3/4PD1AJ
4
Parts Catalog
WINDSHIELD WIPER
5
Parts Diagram
Parts Catalog
WINDSHIELD
by
BRAKE LINES AND MASTER CYLINDER
WINDSHIELD WIPER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
1
1
1
1
2
3
4
5
5
5
6
7
1
WIPER MOTOR
2204914
$307,64 Unit Price incl. VAT
2
WINDSHIELD WIPER ARM
2204915
$54,59 Unit Price incl. VAT
3
WINDSHIELD WIPER BLADE
2204916
$20,99 Unit Price incl. VAT
4
HDWR-WIPER MTR INSTL;WSHLD;TTN
2205572
9999999
Not Available
5
ASM-BOTTLE WASHER WSHLD
2205139
$89,24 Unit Price incl. VAT
6
PUMP-WASHER WIPER FLUID
2205140
$26,24 Unit Price incl. VAT
7
WASHER BOTTLE; WIPER FLUID
5450700
$104,99 Unit Price incl. VAT
8
GROMMET-PUMP WSHR FLUID
5414883
$9,44 Unit Price incl. VAT
9
LID-BOTTLE WASHER BRT
5450701
$10,49 Unit Price incl. VAT
10
WASHER BOTTLE BRACKET; FRONT
5258010
9999999
Not Available
11
WASHER BOTTLE BRACKET; SIDE
5258011
9999999
Not Available
12
HEX FLANGE SCREW; 6 MM X 16 MM
7518548
$3,14 Unit Price incl. VAT
13
WIPER HARNESS
2412622
$377,99 Unit Price incl. VAT
14
MICRO RELAY
4011998
$99,74 Unit Price incl. VAT
15
SEALED CIRCUT BREAKER; 20 AMP
2410881
$141,74 Unit Price incl. VAT
16
SWITCH-WIPER WASH
4014071
9999999
Not Available
17
SWITCH-WIPER LOW HIGH
4014072
$36,74 Unit Price incl. VAT
18
WIPER MOUNT; WINDSHIELD
5450703
9999999
Not Available
19
WASHER FLUID WIPER HOSE
5414882
$89,24 Unit Price incl. VAT
20
COVER-WIPER WSHLD BRT
5450702
9999999
Not Available
21
NYLOCK FLANGE NUT; 6 MM
7547274
7548027
$3,14 Unit Price incl. VAT
22
RETAINER-MOTOR WIPER
5258170
9999999
Not Available
23
HARNESS GUISE
5414966
$89,24 Unit Price incl. VAT
24
HARNESS GUIDE
5415017
$26,24 Unit Price incl. VAT
25
FITTING-BARB HOSE
7052581
$68,24 Unit Price incl. VAT
26
CLIP-HARNESS
7081936
$10,49 Unit Price incl. VAT
27
SCREW
7512026
$2,09 Unit Price incl. VAT
28
TORX SCREW; #14 X 3/4
7519045
$6,29 Unit Price incl. VAT
29
ROUTING CLIP
7081496
$9,44 Unit Price incl. VAT
30
WSHR-6.4X18.0X1.6 ZC
7556565
$4,19 Unit Price incl. VAT

Find the detailed WINDSHIELD WIPER POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
