1
Engine displacement
300
2
Year
1996
3
Trim
XPRESS 300 - W969530
4
Parts Catalog
FRONT WHEEL XPRESS 300 W969540 AND XPRESS 400 W969540 (4935923592B008)
5
Parts Diagram
Parts Catalog
STRUT XPRESS 300 W969540 AND XPRESS 400 W969540 (4935923592B007)
by
HANDLEBAR (300) XPRESS 300 W969530 (4935923592B009)
FRONT WHEEL XPRESS 300 W969540 AND XPRESS 400 W969540 (4935923592B008)
1
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
2
SEAL FRONT HUB
3610020
9999999
Not Available
3
BALL BEARING
3514001
$34,64 Unit Price incl. VAT
4
DISC BRAKE
5211325
9999999
Not Available
5
HUB WHEEL 2WD.
5130940
9999999
Not Available
6
TIRE F(23X7-10) (23x7x10)
5410906
Not Available
7
RIM FRT (SILVER)
1520175117
Not Available
8
RIM VALVE
1525017
$12,59 Unit Price incl. VAT
9
SPACER; HUB; FRONT
5010256
9999999
Not Available
10
WASHER
7555721
$2,09 Unit Price incl. VAT
11
NUT
7542712
$17,84 Unit Price incl. VAT
12
COTTER PIN
7661407
9999999
Not Available
13
HUB CAP
5431018
9999999
Not Available
14
O-RING
5410470
$4,19 Unit Price incl. VAT
15
FLANGED NUT LOCK(10)
7542459
$3,14 Unit Price incl. VAT
16
STUD
7515523
$5,76 Unit Price incl. VAT
17
BOLT
7515321
9999999
Not Available

Find the detailed FRONT WHEEL XPRESS 300 W969540 AND XPRESS 400 W969540 (4935923592B008) POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
