1
Engine displacement
700
2
Year
1997
3
Trim
SL 700 - B974071
4
Parts Catalog
COOLING SYSTEM SL 700 B974071, INTL. SL 700 I974071, SL 700 DELUXE B974072 (4940874087B011)
5
Parts Diagram
Parts Catalog
AIR INTAKE/HULL AIR INLET (INTL. SL 700/INTL. DELUXE) INTL. SL 700 I (4940874087B010)
by
WATER INLET SL 700 B974071, INTL. SL 700 I974071, SL 700 DELUXE B974072 AND (4940874087B012)
COOLING SYSTEM SL 700 B974071, INTL. SL 700 I974071, SL 700 DELUXE B974072 (4940874087B011)
1
CLAMP HOSE SS
7080475
9999999
Not Available
2
CONDUIT FLEX 1.250ID
552128745
Not Available
3
HOSE PUMP OUTLET
5411049
9999999
Not Available
4
FITTING TEE
5431784
9999999
Not Available
5
CLAMP HOSE S.S.
7080476
$11,54 Unit Price incl. VAT
6
FITTING SCREEN
7052128
9999999
Not Available
7
DESC NOT_AVAILABLE
845005416
Not Available
8
FITTING WATER INLET
5020668
9999999
Not Available
9
HOSE INLET
5411050
9999999
Not Available
10
CABLE TIE
7080138
$5,24 Unit Price incl. VAT
11
BOLT
7516727
9999999
Not Available
12
BOLT S.S(10)
7516725
9999999
Not Available
13
MANIFOLD EXH.
1260694
Not Available
14
WASHER; FLAT; S.S.
7555856
9999999
Not Available
15
WASHER LOCKSS.
7552611
9999999
Not Available
16
BOLT S.S.(10)
7517004
9999999
Not Available
17
GASKET EXH.FLNG
5811045
9999999
Not Available
18
VALVE; POP-OFF
5431588
9999999
Not Available
19
THERMOSTAT; (143 F.)
7051008
9999999
Not Available
20
GASKET; THERMOSTAT
5410781
9999999
Not Available
21
COVER THERMOSTAT
5131008
9999999
Not Available
22
SPRING COMPRESSION
7041310
9999999
Not Available
23
SEAL O-RING/THERMO/FITTING
5410860
9999999
Not Available
24
FITTING DRAIN
5020746
9999999
Not Available
25
SCREW SHOULDER S.S.
7515149
9999999
Not Available
26
WASHER
7555836
9999999
Not Available
27
HOSE THERMOSTAT FTG.
5411133
9999999
Not Available

Find the detailed COOLING SYSTEM SL 700 B974071, INTL. SL 700 I974071, SL 700 DELUXE B974072 (4940874087B011) POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
