REAR TORQUE ARM
1
2
2
3
4
5
6
7
8
9
9
9
10
10
10
11
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
13
14
14
14
14
14
14
14
14
14
15
15
15
15
16
17
18
19
20
21
22
23
23
24
25
26
26
27
28
29
30
31
31
32
33
34
1
2
2
3
4
5
6
7
8
9
9
9
10
10
10
11
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
13
14
14
14
14
14
14
14
14
14
15
15
15
15
16
17
18
19
20
21
22
23
23
24
25
26
26
27
28
29
30
31
31
32
33
34
1
GUIDE ADAPTER NUT (Euro)
5131276
Not Available
2
RETAINER SPRING HVY BODY
1500091
9999999
Not Available
3
ADAPTER;NUT;SPRING-RET.
5131274
2871439
Not Available
4
SPRING COMP 190# BLK (Euro)
7041491067
Not Available
5
BOLT
7512589
$3,14 Unit Price incl. VAT
6
LOCK WASHER
7552614
$3,14 Unit Price incl. VAT
7
FLAT WASHER
7555984
$4,19 Unit Price incl. VAT
8
SHAFT RTA UPPER
5020814
9999999
Not Available
9
SCREW
7515433
$3,14 Unit Price incl. VAT
10
FLEXLOC NUT
7542411
$6,29 Unit Price incl. VAT
11
TORSION SPRING SLEEVE
5431923
9999999
Not Available
12
SPRING LH TORS .421 BLK.
7041406067
Not Available
12
SPRING LH TORSION BLK.
7041394067
Not Available
12
SPRING RH TORS .421 BLK.
7041407067
Not Available
12
SPRINGRHTORSIONBLK.
7041395067
Not Available
12
SPRING RH TORS .437/77DG BK
7041488067
Not Available
12
SPRING LH TORS .437/77DG BK
7041487067
Not Available
13
WASHER THRUST
7555787
9999999
Not Available
14
CHAINCASE BEARING
3514305
$34,64 Unit Price incl. VAT
14
RETAINING RING
7718407
$9,44 Unit Price incl. VAT
14
CARRIER WHEEL
1543023
9999999
Not Available
15
COLLAR;BRG LOCK
5010404
9999999
Not Available
15
SCREW-SOCKETSET
7512257
$7,34 Unit Price incl. VAT
16
ARM RR TORQUE(XTRA 12) BLK
1541029067
Not Available
17
FLEX LOC NUT
7542507
9999999
Not Available
18
SHAFT
5020898
9999999
Not Available
19
SCREW
7517248
9999999
Not Available
20
SHOCK GAS R.TRACK ADJ
7041481
9999999
Not Available
21
RETAINER SPRING
5210953
$11,54 Unit Price incl. VAT
22
COMPRESSION SPRING
7041484067
Not Available
23
SHIELD SPRING
5410874
9999999
Not Available
24
PUSH ON CLIP
7080394
$4,19 Unit Price incl. VAT
25
ROLLER SPRING ADJ.
5431909
9999999
Not Available
26
RETAINER SPRING SLOTTED CAST
5630580
5020618
$36,74 Unit Price incl. VAT
27
BUSHING NYLON
3573910
9999999
Not Available
28
ROD SHOCK
1541014067
Not Available
29
SPRING .331 COMP(LT) BLK.
7041404067
Not Available
30
ADJUSTABLE PRELOAD SPRING RING
5431734
$104,99 Unit Price incl. VAT
31
WAVE SPRING WASHER
7555795
$2,09 Unit Price incl. VAT
32
SHOCK F.TRACK ADJ HVY B
7041485
Not Available
33
SPACER
5333028
9999999
Not Available
34
BOLT
7515378
9999999
Not Available

Find the detailed REAR TORQUE ARM POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.

List of compatible models

TOURING autre 1998
