TUNNEL AND SEAT ASSEMBLY LITE 0953433, STARLITE 0953427 AND LITE DELUXE 09 (4928902890A006)
1
GAS CAP WITH GAUGE
2511245
9999999
Not Available
2
GAS CAP GASKET
5810513
$15,74 Unit Price incl. VAT
3
SEAT ASM (LITE) [No Longer Available] (Lite)
2681764
Not Available
3
SEAT ASM (LITE DLX.) (Deluxe)
2681766
Not Available
3
SEAT CUSHION;(STAR/LITE94)
2681678
9999999
Not Available
4
COVER SEAT (StarLite)
2681767
Not Available
4
COVER SEAT (STAR/LITE#94) (Lite Star)
2681679
Not Available
4
COVER SEAT (LITE) (Lite)
2681765
Not Available
5
NYLOK NUT
7542122
$2,09 Unit Price incl. VAT
6
WASHER WROUGHT
7558302
$3,14 Unit Price incl. VAT
7
SCREW
7511840
9999999
Not Available
8
LENS TAILLIGHT
5430423
9999999
Not Available
9
HOUSING TAILLIGHT
5431545
9999999
Not Available
10
BULB
4030045
9999999
Not Available
11
TAILLIGHT HARNESS
2460399
9999999
Not Available
12
SCREW
7515111
9999999
Not Available
13
WASHER
7555798
$1,56 Unit Price incl. VAT
14
FUELPICKUP W/STRAINER
7052037
7052301
$26,24 Unit Price incl. VAT
15
COMPRESSION RING
7080402
$3,14 Unit Price incl. VAT
16
TANK; FUEL
2511215
9999999
Not Available
16
TANK;FUEL;(LITE GT)
2511214
9999999
Not Available
17
FITTING OUTLET
7052023
$36,74 Unit Price incl. VAT
17
FITTING OUTLET
7052056
9999999
Not Available
18
HOSE CLAMP
7080307
$1,56 Unit Price incl. VAT
19
FUEL LINE; 1/4 ID
84500031525
Not Available
20
FITTING 90 DEG 1/8
7052095
$9,44 Unit Price incl. VAT
20
FITTING
7052077
9999999
Not Available
21
DESC NOT_AVAILABLE
8360009175
Not Available
22
RIVET (50)
7621477
9999999
Not Available
23
RECOIL GUIDE
5431385
$19,94 Unit Price incl. VAT
24
RIVET
7661637
$2,09 Unit Price incl. VAT
25
ROPE GUIDE BRACKET; MEDIUM GLOSS BLACK
5222687067
Not Available
26
CABLE TIE
7080138
$5,24 Unit Price incl. VAT
27
BRKT STAND BLK.
5220520067
Not Available
28
RIVET(50)
7621453
9999999
Not Available
29
GROMMET RUBBER
5410021
9999999
Not Available
30
TUNNEL ASM;(LITE)
1011881
9999999
Not Available
31
BRKT CONSOLE/SEAT MT.
5222452067
Not Available
32
CARRIAGE BOLT
7512193
$4,19 Unit Price incl. VAT
33
NUT SPEED
7670021
$10,49 Unit Price incl. VAT
34
STRAP GASTANK BLK.
5222330067
Not Available
35
CUSHION TANK H.D.
5420126
9999999
Not Available
36
RIVET (10)
7661836
9999999
Not Available
37
DECAL TRACK/SEAT(CPSC) (Black)
7074254
Not Available
38
BUMPER REAR
5224480067
Not Available
39
RIVET
7621418
$2,09 Unit Price incl. VAT
40
FLAP SNOWSILVER
5410394
5410394-1038
$194,24 Unit Price incl. VAT
41
SCREW
7512252
9999999
Not Available
42
REFLECTOR RED
2670070
$15,95 Unit Price incl. VAT
43
RIVET (50)
7661837
9999999
Not Available
44
BRKT;RH R.SUSP;BLK.
1011780067
Not Available
44
BRKT LH R.SUSP BLK.
1011779067
Not Available
45
FOOTREST ASMLH
1011830
9999999
Not Available
45
FOOTREST ASMRH(STARLITE)
1011826
9999999
Not Available
46
SUPPORT;LH TRLG.ARM;BLK.
1011792067
Not Available
46
SUPPORT RH TRLG.ARM BLK.
1011793067
Not Available
47
BRKT FR.SUSP BLK.
5220542067
Not Available
48
PAD AIR BOX
5810502
9999999
Not Available
49
BUSHING;SNAP(10)
7080404
9999999
Not Available
50
BULKHEAD (STARLITE) (StarLite GT)
1011885067
Not Available
50
BULKHEAD BLK (94LITE)
1011983067
Not Available
51
HOLE PLUG
7080416
$12,59 Unit Price incl. VAT
52
PLUG HOLE
7080398
$10,49 Unit Price incl. VAT
53
MOUNT;RADIUS ROD
5130759
9999999
Not Available

Find the detailed TUNNEL AND SEAT ASSEMBLY LITE 0953433, STARLITE 0953427 AND LITE DELUXE 09 (4928902890A006) POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.

List of compatible models

OTHERS autre 1995
