1
Engine displacement
850
2
Year
2019
3
Trim
850 SKS 146
4
Parts Catalog
REAR BUMPER, SNOWFLAP AND TAILIGHT COVER
5
Parts Diagram
Parts Catalog
by
MIDDLE FAIRING
REAR BUMPER, SNOWFLAP AND TAILIGHT COVER
1
1
1
1
1
1
2
2
3
4
5
6
7
8
8
8
8
8
8
9
10
10
10
10
10
10
11
11
11
11
11
11
12
13
14
15
16
17
18
19
20
21
22
1
COVER-TAILLIGHT HRNS 144 BLK
5260985067
Not Available
1
COVER-TAILLIGHT HRNS 144 ORG
5260985647
Not Available
1
COVER-TAILLIGHT HARNESS 144
5260985
$136,49 Unit Price incl. VAT
1
COVER-TAILLIGHT HRNSS 144 IRED
5260985293
Not Available
1
COVER-TAILLIGHT HRNS 144 ISKYB
5260985737
Not Available
1
COVER-TAILLIGHT HRNS 144 LMSQZ
5260985630
Not Available
2
RIVET-4.8MM DIA-1.5-6.0GRIP(4)
7662251
$3,66 Unit Price incl. VAT
3
RIVET
7621433
$2,09 Unit Price incl. VAT
4
TAILLIGHT COVER; GLOSS BLACK
5452369070
Not Available
5
HEX FLANGE NUT; 6 MM X 1.0 MM
7547453
$7,34 Unit Price incl. VAT
6
SCR-TXPH-M6X1.0X25 8.8 ZOD
7519993
$2,09 Unit Price incl. VAT
7
TUBE PLUG
7081210
$7,34 Unit Price incl. VAT
8
BUMPER MOUNT; INDIAN SKY BLUE
5137501737
Not Available
8
BUMPER MOUNT; INDY RED
5137501293
Not Available
8
BUMPER MOUNT; ORANGE BURST
5137501647
Not Available
8
BUMPER MOUNT; MEDIUM GLOSS BLACK
5137501067
Not Available
8
BUMPER MOUNT
5137501
$73,49 Unit Price incl. VAT
8
BUMPER MOUNT; LIME SQUEEZE
5137501630
Not Available
9
BUMPER TUBE; MEDIUM GLOSS BLACK
5339046067
Not Available
10
ASM-BUMPER RR RMK AL GBK/OBST
10178511697
Not Available
10
BMPR ASM RR GS BLK W/ IND SKY BLUE RMK
10178511696
Not Available
10
BUMPER ASM REAR GS BLK W/ LIME SQUEEZE
10178511698
Not Available
10
BUMPER ASM REAR GS BLK W/ NATURAL RMK
10178511209
Not Available
10
BUMPER ASSEMBLY; REAR; GS BLK; RMK
1017851067
Not Available
10
ASM-BUMPER RR RMK AL GBK/IRED
10178511695
Not Available
11
ASM-CLOSEOFF REAR BLK
1021309067
Not Available
11
ASM-CLOSEOFF REAR ORANGEBURST
1021309647
Not Available
11
CLOSEOFF ASSEMBLY; REAR; INDIAN SKY BLUE
1021309737
Not Available
11
CLOSEOFF ASSEMBLY; REAR
1021309
9999999
Not Available
11
ASM-CLOSEOFF REAR IRED
1021309293
Not Available
11
ASM-CLOSEOFF REAR LIME SQZ
1021309630
Not Available
12
RIVET 4.8 MM
7661973
$2,09 Unit Price incl. VAT
13
RIVET
7621467
$2,09 Unit Price incl. VAT
14
FLAP-SNOW BLK
5454820070
Not Available
15
SCR-TXTH-M6X1.0X15 ZPB TAP
7519092
$2,09 Unit Price incl. VAT
16
SCR-TXPH-M6X1.0X45 8.8 ZBLK
7520466
$10,49 Unit Price incl. VAT
17
SPACER-TUNNEL PROTECTOR
5140052
$9,44 Unit Price incl. VAT
18
PROTECTOR-TUNNEL NAT
5522135309
Not Available
19
WSHR-6.4X18.0X1.6 ZC
7556565
$4,19 Unit Price incl. VAT
20
NYLOK NUT
7546703
$2,09 Unit Price incl. VAT
21
NUT-ACORN M5 BLK
7547286
$6,29 Unit Price incl. VAT
22
WSHR-FL 5.5X1.0
7556071
$9,44 Unit Price incl. VAT

Find the detailed REAR BUMPER, SNOWFLAP AND TAILIGHT COVER POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
