BRAKES, PEDAL AND MASTER CYLINDER MOUNTING for POLARIS ACE 150 EFI MD from 2021

BRAKES, PEDAL AND MASTER CYLINDER MOUNTING

1

WELD-PEDAL BRAKE RED

1022924239

Not Available

2

MASTER CYLINDER ASSEMBLY; DUAL BORE

1912811

$519,74 Unit Price incl. VAT

3

BRKT-CLEVIS

5263493

9999999

Not Available

4

BRKT-MC BOOT RETAINER

5263509

9999999

Not Available

5

BRKT-MNT BRAKE PEDAL BLK

5263519458

Not Available

6

SEAL-MC BOOT

5416095

9999999

Not Available

7

NUT-HEX-M8X1.25 8ZPB;LH;THR

7547851

$7,34 Unit Price incl. VAT

8

PEDAL BUSHING PIVOT

5439274

$24,14 Unit Price incl. VAT

9

CAST-COUPLER BRAKE PUSH ROD

5633731

$19,94 Unit Price incl. VAT

10

SPRING

7041789

$16,79 Unit Price incl. VAT

11

WASHER-.937X.501X.031 OLIVE D

7556376

$6,29 Unit Price incl. VAT

12

CLIP PIN; 14 MM

7661140

$2,09 Unit Price incl. VAT

13

CLEVIS PIN; 1/4 X 3/4

7661843

$4,19 Unit Price incl. VAT

14

PIN-CLIP

7662424

9999999

Not Available

15

PIN-PIVOT BRAKE PEDAL

7662312

$17,84 Unit Price incl. VAT

16

HEX FLANGE SCREW; 8 MM X 30 MM

7518884

$3,66 Unit Price incl. VAT

17

NYLOC OLIVE NUT; 8 MM X 1.25 MM

7547332

$7,34 Unit Price incl. VAT

18

BRAKE PUSH ROD

1912814

9999999

Not Available

19

HEX FLANGE SCREW; 6 MM X 1.0 MM X 12 MM

7519145

$7,34 Unit Price incl. VAT

20

HEX HEAD NUT; 8 MM

7547076

$4,19 Unit Price incl. VAT

21

NUT-HEX-M8X1.25 8 ZPC

7547975

Not Available

Find the detailed BRAKES, PEDAL AND MASTER CYLINDER MOUNTING POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
