1
Engine displacement
1000
2
Year
2020
3
Trim
GENERAL 1000 XP 4 SEAT
4
Parts Catalog
FRONT SUSPENSION SHOCK INTERNALS
5
Parts Diagram
Parts Catalog
FRONT SUSPENSION CONTROL ARMS
by
SUSPENSION, REAR STRUT STABILIZER
FRONT SUSPENSION SHOCK INTERNALS
1
1
1
1
4
5
6
7
8
1
1
11
12
13
14
14
1
16
1
18
1
20
21
21
21
22
22
23
24
25
26
1
28
29
30
31
32
33
1
1
1
1
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
2
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
3
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
4
BALL-D-TENT(10)
1800127
$12,59 Unit Price incl. VAT
5
SPRING-D-TENT(10)
1800128
$20,99 Unit Price incl. VAT
6
END CAP SNAP RING
1800041
$15,74 Unit Price incl. VAT
7
BODY O-RING
1800030
$3,66 Unit Price incl. VAT
8
D/TYPE WIPER
1800034
$68,24 Unit Price incl. VAT
9
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
10
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
11
BRIDGE-2.0 ADJ;CLR 1720001-AC
1800921
$246,74 Unit Price incl. VAT
12
NEEDLE-1PC PRESS IN 1620008
1800861
$99,74 Unit Price incl. VAT
13
CAP-WIPER 2.0 1520122-AC
1800794
$83,99 Unit Price incl. VAT
14
KNOB; CLICKER BLACK
1800418
$173,24 Unit Price incl. VAT
15
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
16
ASM-CLICKER STUD 404613
1800758
$47,24 Unit Price incl. VAT
17
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
18
SCREW 10X5/8 BTN SS (500603)
1800357
$6,29 Unit Price incl. VAT
19
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
20
RING-RETAINING 1520119
1800862
$11,54 Unit Price incl. VAT
21
RING-RET. WIRE 1520120
1800795
$15,74 Unit Price incl. VAT
22
O-RING; 2-226 1600018
1800863
$9,44 Unit Price incl. VAT
23
O-RING
1800184
$10,49 Unit Price incl. VAT
24
SCREW-#8 LOW HD 1600025
1800843
$9,44 Unit Price incl. VAT
25
O-RING; 2-108 1600026
1800864
$9,44 Unit Price incl. VAT
26
SPRING NUT-2 CLEAR 1620014-AC
1800865
$73,49 Unit Price incl. VAT
27
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
28
O-RING
1800810
$6,81 Unit Price incl. VAT
29
BEARING-HKFS8T-10MM 1600130
1800809
$80,84 Unit Price incl. VAT
30
0-RING 5MM ID X 2MM 1600073
1801031
$3,14 Unit Price incl. VAT
31
NUT 7/16 NYLOCK (1425112)
1800638
$9,44 Unit Price incl. VAT
32
SPRING RETAINER
5633421
5634606
$141,74 Unit Price incl. VAT
33
2.0 END CAP ASM;WR;PORT
1801044
$136,49 Unit Price incl. VAT
34
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
35
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
36
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available

Find the detailed FRONT SUSPENSION SHOCK INTERNALS POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
