1
Engine displacement
330
2
Year
2004
3
Trim
ATP 330 4X4 - A04JD32AA
4
Parts Catalog
CONTROLS-MASTER CYLINDER/BRAKE LINE
5
Parts Diagram
Parts Catalog
FRONT WHEEL
by
REAR BRAKE
CONTROLS-MASTER CYLINDER/BRAKE LINE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
2
Clamp Brake Line
5434041
Not Available
3
SCREW
7512084
$2,09 Unit Price incl. VAT
4
SCREW
7517386
$2,09 Unit Price incl. VAT
5
CLAMP RUBBER-COATED .562
7080573
$13,64 Unit Price incl. VAT
6
LINE-BRAKE JB TO FT M/C
1910657
9999999
Not Available
7
CLAMP NYLON CABLE
7080539
$9,44 Unit Price incl. VAT
8
RIVET
7621462
$2,09 Unit Price incl. VAT
9
BRAKE LINE POD; STAINLESS; 22.56
1910470
$167,99 Unit Price incl. VAT
10
CROSS FITTING
7052292
$73,49 Unit Price incl. VAT
11
BRAKE LINE; FRONT; RIGHT
1910475
$167,99 Unit Price incl. VAT
12
CONDUIT; 34 CM.
836003134
Not Available
13
CABLE TIE
7080138
$5,24 Unit Price incl. VAT
14
BRAKE LINE; FRONT; LEFT; STAINLESS
1910474
$167,99 Unit Price incl. VAT
15
SCREW
7512024
$9,44 Unit Price incl. VAT
16
STOPLIGHT SWITCH
4110164
2890637
$325,49 Unit Price incl. VAT
17
BOOT BRAKELINE RUBBER
5411297
9999999
Not Available
18
BANJO BOLT; 10 MM X 1.00
1910499
$10,49 Unit Price incl. VAT
19
SEAL (10)
5410988
9999999
Not Available
20
MASTER CYL;3/4";BAN;WW;LH;ASM.
2010196
2010238
$456,74 Unit Price incl. VAT

Find the detailed CONTROLS-MASTER CYLINDER/BRAKE LINE POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
