GEARCASE for POLARIS XPLORER 400 - A00CG38CA from 2000

GEARCASE HLR HYBRID 4X4

1341273

9990000

Not Available

SCREW

3233525

9999999

Not Available

WASHER

3233054

9999999

Not Available

DAMPENER CARB.VIBRATION

3233526

9999999

Not Available

PLUG

3233448

9999999

Not Available

WASHER

3233035

9999999

Not Available

PIVOT BUSHING

3233527

9999999

Not Available

SCREW

3233252

$9,44 Unit Price incl. VAT

GEARCASE-LH

3233632

9999999

Not Available

KNOCK PIPE

3233529

9999999

Not Available

BEARING

3233020

$80,84 Unit Price incl. VAT

GEAR 98T HCR.

3233558

9999999

Not Available

OUTPUT SHAFT

3233544

9999999

Not Available

SPROCKET 16/26T

3233545

9999999

Not Available

ROLLER CHAIN

3233546

9999999

Not Available

SEAL

3233248

3233788

$57,74 Unit Price incl. VAT

WASHER THRUST

3233542

9999999

Not Available

GARLOCK BUSHING

3233541

9999999

Not Available

PINION SHAFT; 13 TOOTH

3233540

9999999

Not Available

RETAINING RING

3233306

$9,44 Unit Price incl. VAT

COVER-BEARING

3233263

9999999

Not Available

SCREW

3233539

9999999

Not Available

SPROCKET 14/22T

3233538

9999999

Not Available

RING RETAINING

3233537

9999999

Not Available

SHAFT-INPUT HIGH/LOW/REVERSE

3233704

9999999

Not Available

BEARING

3233018

$47,24 Unit Price incl. VAT

WASHER

3233176

$17,84 Unit Price incl. VAT

BEARING; NEEDLE

3233009

$68,24 Unit Price incl. VAT

ENGAGEMENT-DOG LOW

3233666

9999999

Not Available

BEARING

3233019

$54,59 Unit Price incl. VAT

WASHER

3233010

9999999

Not Available

SPROCKET 24T 12-POINT

3233532

9999999

Not Available

RING RETAINING

3233029

9999999

Not Available

SILENT CHAIN

3233036

9999999

Not Available

GEAR 30T 12-POINT

3233535

9999999

Not Available

RING RETAINING

3233177

9999999

Not Available

BUSHING GARLOCK

3233534

9999999

Not Available

DOG ENGAGE 12PT HI/REV

3233533

9999999

Not Available

WASHER

3233012

9999999

Not Available

NEEDLE BEARING

3233014

$74,54 Unit Price incl. VAT

SHAFT-REVERSE 31T

3233703

9999999

Not Available

GEAR33T

3233665

9999999

Not Available

SHIFT FORK; LOW

3233706

9999999

Not Available

FORK SHIFT HIGH/REV

3233633

9999999

Not Available

BELLCRANK

3233547

9999999

Not Available

NUT

3233055

3233961

$5,24 Unit Price incl. VAT

BELLCRANK

3233153

$62,99 Unit Price incl. VAT

RETAINING RING

3233045

$9,44 Unit Price incl. VAT

WASHER

3233040

9999999

Not Available

O-RING

3233548

9999999

Not Available

SHAFT SHIFT

3233549

9999999

Not Available

SCREW

3233691

3233749

$10,49 Unit Price incl. VAT

DECAL-SWITCH

3233636

9999999

Not Available

SWITCH-H/R ITW

3233635

9999999

Not Available

SWITCH ITW 2 POSITION

3233617

9999999

Not Available

VENT

3233037

9999999

Not Available

COVER SNORKEL

3233556

9999999

Not Available

O-RING

3233555

9999999

Not Available

SHIM

3233554

$62,99 Unit Price incl. VAT

GEAR SNORKEL

3233553

Not Available

GARLOCK BUSHING

3233552

$41,99 Unit Price incl. VAT

WASHER

3233324

9999999

Not Available

DIPSTICK (PLUG)

3233325

9999999

Not Available

GEARCASE

3233705

9999999

Not Available

OIL DEFLECTOR

3233043

9999999

Not Available

SCREW

3233033

9999999

Not Available

BRACKET INTERLOCK

3233309

9999999

Not Available

SPRING

3233032

9999999

Not Available

PIN INTERLOCK

3233308

9999999

Not Available

Find the detailed GEARCASE POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
