STRUT ASSEMBLY 2X4 300 W957530 (4930053005B002)
5
Parts Diagram
Parts Catalog
FAN ASSEMBLY 2X4 300 W957530 (4930053005A011)
by
FRONT WHEEL ASSEMBLY 2X4 300 W957530 (4930053005B003)
STRUT ASSEMBLY 2X4 300 W957530 (4930053005B002)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
16
16
16
16
17
1
FLEX LOC NUT
7542507
9999999
Not Available
2
WASHER
7555749
$2,09 Unit Price incl. VAT
3
SPACER RUBBER
5810291
$7,34 Unit Price incl. VAT
4
PIVOT BALL; TOP
5430806
5432872
$19,94 Unit Price incl. VAT
5
PIVOT BALL;BOTTOM
5430807
5432871
$19,94 Unit Price incl. VAT
6
THREADED SPACER
5130668
$52,49 Unit Price incl. VAT
7
RETAINER SPRING TOP
5220602
9999999
Not Available
8
SPRING COIL FR.SHOCK
7041238067
Not Available
9
BUMPER RUBBER
5410429
9999999
Not Available
10
STRUT ASSMEBLY FRONT 25 MM
7041451
9999999
Not Available
11
CLAMP RUBBER-COATED .562
7080573
$13,64 Unit Price incl. VAT
12
NUT FLEX-LOC
7542303
9999999
Not Available
13
BOLT
7515339
$9,44 Unit Price incl. VAT
14
FLAT WASHER
7558402
$1,56 Unit Price incl. VAT
15
FITTING LUBE.W/BALL CK.(10)
7080306
$5,76 Unit Price incl. VAT
16
SUPPORTRH STRUT
5130804
9999999
Not Available
16
SUPPORT LH STRUT
5130803
Not Available
17
WASHER
5211115
$7,34 Unit Price incl. VAT

Find the detailed STRUT ASSEMBLY 2X4 300 W957530 (4930053005B002) POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
