1
Engine displacement
780
2
Year
1996
3
Trim
INTL SLX 780 - I964287
4
Parts Catalog
STEERING SLX 780 B964287 AND INTL. SLX 780 I964287 (4937443744A013)
5
Parts Diagram
Parts Catalog
OIL TANK SLX 780 B964287 AND INTL. SLX 780 I964287 (4937443744A012)
by
STEERING SLX 780 B964287 AND INTL. SLX 780 I964287 (4937443744A014)
STEERING SLX 780 B964287 AND INTL. SLX 780 I964287 (4937443744A013)
13
13
14
15
16
17
18
19
20
21
22
23
24
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
13
13
14
15
16
17
18
19
20
21
22
23
24
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
1
THROTTLE CONTROL ASM.
2010122
9999999
Not Available
2
RING RETAINING EXT. S.S.
7710426
9999999
Not Available
3
WASHER; FLAT; S.S.
7555840
9999999
Not Available
4
SCREW; SET; S.S.
7515115
9999999
Not Available
5
PIN; RETAINING
7661628
9999999
Not Available
6
LEVER THROTTLE CONTROL
5431397
9999999
Not Available
7
BLOCKTHROTTLE CONTROL
5431396
9999999
Not Available
8
CABLE THROTTLE
7080504
9999999
Not Available
9
FUEL LINE (427 CM.)
8450058427
Not Available
10
GAUGEMULTI-FUNCTION
3280252
9999999
Not Available
11
HARNESS WIRE MFD(SL)
2460518
9999999
Not Available
12
PAD;HBAR;P.RED
5431957136
Not Available
13
SCREW; SS.
7512047
9999999
Not Available
14
SWITCH STOP/TRIM/TETHER
4110162
Not Available
15
PLUG HANDGRIP BLK.
7010082070
Not Available
16
GRIP;HBAR;P.RED
5410638136
Not Available
17
CAPLUG
7080467
9999999
Not Available
18
SCREW
7516602
9999999
Not Available
19
CORD; TETHER
7080518
9999999
Not Available
20
SCREW; S.S.
7516601
9999999
Not Available
21
BOLT SHOULDER(10)
7515387
9999999
Not Available
22
STOP STEERING
5222677
9999999
Not Available
23
BUSH.
7555875
9999999
Not Available
24
BUSHING STRG.SUPPORT
5431382
9999999
Not Available
25
SUPPORT STRG.HUB BLK.
5130974067
Not Available
26
PLATE BOLT
1060101
9999999
Not Available
27
NUT HEX S.S.
7541931
$9,44 Unit Price incl. VAT
28
WASHER; FLAT; S.S.
7555837
9999999
Not Available
29
ROD END; S.S.
7060154
9999999
Not Available
30
NUT (10)
1860102
9999999
Not Available
31
BOLT; S.S.
7512041
9999999
Not Available
32
ARMSTEERINGBLK.
5130958067
Not Available
33
WASHER LOCK S.S.
7552610
9999999
Not Available
34
BOLT; S.S.
7515375
9999999
Not Available
35
NUT HEX S.S.(10)
7542335
Not Available
36
SCREW S.S.(10)
7512074
9999999
Not Available
37
BRKT RECEIVER
5431427
Not Available
38
POST STEERING W/H BAR
1823175
9999999
Not Available
39
CABLE TIE
7080138
$5,24 Unit Price incl. VAT

Find the detailed STEERING SLX 780 B964287 AND INTL. SLX 780 I964287 (4937443744A013) POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
