1
Engine displacement
900
2
Year
2013
3
Trim
RZR XP 900 EPS INTL - R13JT9EFX
4
Parts Catalog
DRIVE TRAIN, MAIN GEARCASE INTERNALS
5
Parts Diagram
Parts Catalog
DRIVE TRAIN, FRONT GEARCASE
by
DRIVE TRAIN, PRIMARY CLUTCH
DRIVE TRAIN, MAIN GEARCASE INTERNALS
24
25
25
25
26
27
28
28
29
30
30
31
32
33
34
35
36
37
34
39
40
41
42
43
44
45
46
47
47
48
49
50
51
52
53
54
55
56
57
58
59
59
60
61
61
61
62
63
64
65
65
66
67
68
24
25
25
25
26
26
27
1
ASM-GEARCASE COMPLETE DIFF
1333063
9999999
Not Available
2
SCREW 6 MM X 1.0 MM 40 MM
3235208
$20,99 Unit Price incl. VAT
3
SOCKET HEAD SCREW; 6 MM X 1 MM X 18 MM
3235332
$7,34 Unit Price incl. VAT
4
SCREW; TORX PAN HD M6 X 1 X 16
3234309
$13,64 Unit Price incl. VAT
5
CUP WASHER
3234091
$17,84 Unit Price incl. VAT
6
WASHER-FENDER 5/16-1.25
3234952
$13,64 Unit Price incl. VAT
7
WASHER
3235211
$19,94 Unit Price incl. VAT
8
WASHER
3235212
$25,19 Unit Price incl. VAT
9
WASHER
3235213
$31,49 Unit Price incl. VAT
10
SNAP RING
3233106
$10,49 Unit Price incl. VAT
11
RETAINING RING
3233364
$12,59 Unit Price incl. VAT
12
EXTERNAL RETAINING RING
3234318
$5,76 Unit Price incl. VAT
13
RING RETAININGBASICINTRNL2.047
3234269
$17,84 Unit Price incl. VAT
14
RETAINING RING
3234090
$19,94 Unit Price incl. VAT
15
RETAINING RING
3234205
$20,99 Unit Price incl. VAT
16
RETAINING RING
3235214
$17,84 Unit Price incl. VAT
17
RETAINING RING
3235216
$19,94 Unit Price incl. VAT
18
THRUST WASHER
3233378
$17,84 Unit Price incl. VAT
19
SHIM 1.180 X .995(9)
3234272
$68,24 Unit Price incl. VAT
20
SHIM; 2.040 OD X 1.630 ID
3234273
$26,24 Unit Price incl. VAT
21
NEEDLE BEARING
3233014
$74,54 Unit Price incl. VAT
22
BEARING
3233019
$54,59 Unit Price incl. VAT
23
BEARING
3233020
$80,84 Unit Price incl. VAT
24
BALL BEARING
3233268
$88,19 Unit Price incl. VAT
25
BALL BEARNING
3234065
$80,84 Unit Price incl. VAT
26
NEEDLE BEARING
3233384
$54,59 Unit Price incl. VAT
27
BALL BEARING
3235218
$101,84 Unit Price incl. VAT
28
BALL BEARING
3234652
$27,29 Unit Price incl. VAT
29
BALL BEARING
3235328
$54,59 Unit Price incl. VAT
30
COMPRESSION SPRING
3234078
$47,24 Unit Price incl. VAT
31
COMPRESSION SPRING
3234089
$52,49 Unit Price incl. VAT
32
TORSION RETURN SPRING
3234276
$16,79 Unit Price incl. VAT
33
SNORKLE TUBE
3234278
$188,99 Unit Price incl. VAT
34
SHIFT DRUM
3235463
$519,74 Unit Price incl. VAT
35
IDLER SHAFT; 29 TOOTH
3235223
$204,74 Unit Price incl. VAT
36
REVERSE SHAFT; 29 TOOTH
3235224
$272,99 Unit Price incl. VAT
37
OUTPUT SHAFT; FRONT
3235225
$225,74 Unit Price incl. VAT
38
SHIFT DRUM
3235463
$519,74 Unit Price incl. VAT
39
PINION SUBASSEMBLY
3235371
$782,24 Unit Price incl. VAT
40
DISC BRAKE
3235372
$120,74 Unit Price incl. VAT
41
SHIFT COLLAR
3234073
$57,74 Unit Price incl. VAT
42
SHIFT RAIL; SHAFT
3235542
$52,49 Unit Price incl. VAT
43
FORK SHIFT
3235455
$173,24 Unit Price incl. VAT
44
ENGAGEMENT DOG
3234928
$136,49 Unit Price incl. VAT
45
PARK/LOW SHIFT DOG
3235457
$272,99 Unit Price incl. VAT
46
STAGE 2 GEAR; 44 TOOTH
3235229
$173,24 Unit Price incl. VAT
47
SHIFT FORK SUBASSEMBLY
3235454
$167,99 Unit Price incl. VAT
48
SPROCKET; 48 TOOTH; 6 FACE
3235231
$152,24 Unit Price incl. VAT
49
LOW GEAR; 67 TOOTH
3235232
$230,99 Unit Price incl. VAT
50
6 FACE ENGAGEMENT DOG
3235233
$241,49 Unit Price incl. VAT
51
GEAR; 53 TOOTH
3235234
$157,49 Unit Price incl. VAT
52
STAGE 3 GEAR; 46 TOOTH
3235236
$204,74 Unit Price incl. VAT
53
OUTPUT GEAR; FRONT; 13 TOOTH
3235237
$246,74 Unit Price incl. VAT
54
LOCKING DIFFERENTIAL
3235373
$771,74 Unit Price incl. VAT
55
FORK RETAINER
3234934
$19,94 Unit Price incl. VAT
56
CENTER DRIVE BEARING COVER
3235241
$89,24 Unit Price incl. VAT
57
SILENT CHAIN
3234737
$314,99 Unit Price incl. VAT
58
HI TEMP TRI LIP SEAL; 25 X 80 X 10
3235658
$104,99 Unit Price incl. VAT
59
EXPANSION PLUG; 1 1/4
3234249
$25,19 Unit Price incl. VAT
60
GEAR SUBASSEMBLY; 39 TOOTH; SIDE
3235374
$351,74 Unit Price incl. VAT
61
PLAIN BEARING; 40 X 44 X 15
3234241
$27,29 Unit Price incl. VAT
62
GEAR SUBASSEMBLY; 39 TOOTH; SIDE
3235375
$351,74 Unit Price incl. VAT
63
COVER SUBASSEMBLY
3235376
$262,49 Unit Price incl. VAT
64
GEAR SUBASSEMBLY
3234469
$136,49 Unit Price incl. VAT
65
SCREW-CAP HH;M8 X 1.25 X 20
3235096
3236169
$17,84 Unit Price incl. VAT
66
GEAR SUBASSEMBLY; 53 TOOTH
3235378
9999999
Not Available
67
PLAIN BEARING; 10 X 12 X 25
3234239
$27,29 Unit Price incl. VAT
68
SLEEVE INPUTSHAFT(150465)
3235465
9999999
Not Available

Find the detailed DRIVE TRAIN, MAIN GEARCASE INTERNALS POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
