REAR SUSPENSION AND TRACK for POLARIS 800 SWITCHBACK PRO-X from 2015

REAR SUSPENSION AND TRACK

1

HEX FLANGE SCREW; 10 MM X 1.5 MM 35 MM

7518957

$6,29 Unit Price incl. VAT

2

HEX FLANGE SCREW; 10 MM X 1.5 MM X 40

7519216

$9,44 Unit Price incl. VAT

3

WASHER

7556042

7555806

$1,56 Unit Price incl. VAT

4

NYLOC NUT

7547333

$3,14 Unit Price incl. VAT

5

CLIP-TRACK FLAT 012-0107 (10

5251273

$18,89 Unit Price incl. VAT

5

TRACK-15X137 1.75 BACKCOUNTRY

5414895

9999999

Not Available

5

LONG GUIDE TRACK CLIP

5251274

$13,64 Unit Price incl. VAT

6

SPRING WASHER; .406 X 1.25 X .125

7556490

$9,44 Unit Price incl. VAT

7

BEARING-.7874X1.6535X.4724 NTN

3514384

3515142

$34,64 Unit Price incl. VAT

7

SUSPENSION RAIL IDLER WHEEL 6.38 IN.

1590512

$72,96 Unit Price incl. VAT

7

RETAINING RING

7710444

$15,74 Unit Price incl. VAT

8

SPACER; IDLER

5432535

$20,99 Unit Price incl. VAT

9

SPACER IDLER CENTER

5333283

$27,29 Unit Price incl. VAT

10

BUSHING

7555918

$3,14 Unit Price incl. VAT

11

SHAFT-IDLER M10X1.5THDX336 LG

5136745

$62,99 Unit Price incl. VAT

12

CROSS SHAFT; MACHINED

5139172

$47,24 Unit Price incl. VAT

13

HEX FLANGE SCREW 10MM X 1.25MM X 250MM

7519327

$36,74 Unit Price incl. VAT

14

SPACER-FTA

5450572

9999999

Not Available

15

WASHER-30MM ODX 21MM ID X 1.5

7556483

$7,34 Unit Price incl. VAT

16

SHAFT-FTA LWT LOWER

5138653

$52,49 Unit Price incl. VAT

17

WSHR-10.4X28.58X2.4 ZOD

7556563

$6,29 Unit Price incl. VAT

18

WSHR-.719X1.250X.065-Y

7556210

$7,34 Unit Price incl. VAT

19

WASHER

7555832

$4,19 Unit Price incl. VAT

20

SHOCK CENTERING LIGHTWEIGHT SPACER

5450477

$15,74 Unit Price incl. VAT

21

SHAFT 17.45 X 214.77

5137312

$52,49 Unit Price incl. VAT

22

SFT-M10X1.5IDX17.47ODX220.1 LG

5136572

$52,49 Unit Price incl. VAT

23

PLAIN WHEEL ASSEMBLY; RACE

1590426

$125,99 Unit Price incl. VAT

Find the detailed REAR SUSPENSION AND TRACK POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
