1
Engine displacement
500
2
Year
2001
3
Trim
SCRAMBLER 500 4X4 - A01BG50AA
4
Parts Catalog
REAR WHEEL
5
Parts Diagram
Parts Catalog
REAR BRAKE MASTER CYLINDER
by
SWING ARM SHOCK
REAR WHEEL
1
1
2
2
3
4
4
5
5
6
6
7
7
8
8
9
9
10
11
12
1
1
2
2
3
4
4
5
5
6
6
7
7
8
8
9
9
10
11
12
1
BOLT
7512673
$5,76 Unit Price incl. VAT
2
HUB KIT
2200341
9999999
Not Available
3
NUT
7547037
9999999
Not Available
4
CONE WASHER
7555796
$14,69 Unit Price incl. VAT
5
CASTLE NUT
7543005
9999999
Not Available
6
COTTER PIN
7661404
$9,44 Unit Price incl. VAT
7
COVER DUST HUB
5411164
5413427
$52,49 Unit Price incl. VAT
8
WASHER
7555745
9999999
Not Available
9
RIM VALVE
1525017
$12,59 Unit Price incl. VAT
10
PUSHNUT BOLT
7670081
9999999
Not Available
11
RIM-REAR 8.5/10SILVER
1520183117
Not Available
12
TIRE-22X11-10;TITAN 489;2 STAR
5412323
5419042
$211,56 Unit Price incl. VAT

Find the detailed REAR WHEEL POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
