1
Engine displacement
550
2
Year
2016
3
Trim
550 INDY VOYAGEUR 144
4
Parts Catalog
CHASSIS, CHASSIS ASM. AND OVER STRUCTURE
5
Parts Diagram
Parts Catalog
NOSEPAN ASM.
by
CHASSIS, CLUTCH GUARD AND FOOTRESTS
CHASSIS, CHASSIS ASM. AND OVER STRUCTURE
1
SCR-HXFL-M8X1.25X50 DP ZODP30
7519245
$7,34 Unit Price incl. VAT
2
BULB SEAL .375 350 CM
5521697350
Not Available
3
TUBE CAST SPACER
5632200
$26,24 Unit Price incl. VAT
4
ASM-FRAME TUBLR REAR;550
1018226
1024447
$1 186,49 Unit Price incl. VAT
5
PAD-RUBBER 1.0 X 2.50 X.13
5813729
$52,49 Unit Price incl. VAT
6
STUD PLATE ASSEMBLY
1018776
$27,29 Unit Price incl. VAT
7
NYLOC OLIVE NUT; 8 MM X 1.25 MM
7547332
$7,34 Unit Price incl. VAT
8
PAD-5X5CM
5813593
$8,39 Unit Price incl. VAT
9
PAD-6.5X25CM
5813662
$7,34 Unit Price incl. VAT
10
KIT-CHASSIS 144 F/C;NAT
2205277309
Not Available
10
ASM-TUNNEL 144 F/C SVC NAT
1018223309
Not Available
11
RIVET 4.8 MM
7661973
$2,09 Unit Price incl. VAT
12
SUPPORT AND GRIPPER TUBE; LEFT
5137724
$414,74 Unit Price incl. VAT
13
TUBULAR FRAME ASSEMBLY; FRONT; RMK
1016954
9999999
Not Available
14
HEX FLANGE SCREW; 8 MM X 1.25 MM X 25 MM
7519243
$7,34 Unit Price incl. VAT
15
NUT-M6X1.0 FLG-NYLOC-OLIVE D
7547339
$2,09 Unit Price incl. VAT
16
BOLT-M6X1.0X15 HXFLG TAP/R-OD
7518513
9999999
Not Available
17
BRKT-COIL MOUNT
5256520
$26,24 Unit Price incl. VAT
18
SCR-HXFL-M6X1.0X55 8.8 ZOD
7519171
7521331-55
$10,49 Unit Price incl. VAT
19
RESONATOR MOUNT; UPPER
5137797
$68,24 Unit Price incl. VAT

Find the detailed CHASSIS, CHASSIS ASM. AND OVER STRUCTURE POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
