1
Engine displacement
425
2
Year
2001
3
Trim
XPEDITION 425 - A01CK42AA
4
Parts Catalog
CLUTCH
5
Parts Diagram
Parts Catalog
MAGNETO
by
TOOL KIT
CLUTCH
1
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
16
17
17
18
19
20
20
21
22
23
24
25
26
27
28
29
29
29
30
30
31
32
33
33
34
35
36
37
38
39
39
40
41
42
43
44
45
46
47
47
1
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
16
17
17
18
19
20
20
21
22
23
24
25
26
27
28
29
29
29
30
30
31
32
33
33
34
35
36
37
38
39
39
40
41
42
43
44
45
46
47
47
1
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
16
17
17
18
19
20
20
21
22
23
24
25
26
27
28
29
29
29
30
30
31
32
33
33
34
35
36
37
38
39
39
40
41
42
43
44
45
46
47
47
1
2
3
4
5
6
7
7
7
8
9
1
SHAFT-SHIFT FORK
3086375
9999999
Not Available
2
FORK SHIFT DRIVEN
3086377
9999999
Not Available
3
BOLT LOCK
3086370
9999999
Not Available
4
WASHER
3086369
9999999
Not Available
5
CAM SHIFT
3086368
9999999
Not Available
6
BEARING-BALL
3086373
9999999
Not Available
7
PIN
3086371
Not Available
8
SHIFT DRUM ASSEMBLY
3086366
9999999
Not Available
8
DRUM SHIFT
3086367
9999999
Not Available
9
PIN DOWEL
3086379
9999999
Not Available
10
FORK SHIFT DRIVE
3086376
9999999
Not Available
11
BEARING-BALL
3086348
9999999
Not Available
12
WASHER
3086350
9999999
Not Available
13
GEAR 2ND DRIVE
3086341
9999999
Not Available
14
COLLAR
3086345
9999999
Not Available
15
GEAR;5TH DRIVE
3086344
9999999
Not Available
16
WASHER
3086346
9999999
Not Available
17
RING SNAP
3086349
9999999
Not Available
18
GEAR 4TH DRIVE
3086343
9999999
Not Available
19
GEAR 3RD DRIVE
3086342
9999999
Not Available
20
SHAFT-MAIN
3086340
9999999
Not Available
20
SHAFT MAIN
3086339
9999999
Not Available
21
PIN
3086372
9999999
Not Available
22
BEARING-BALL
3086347
9999999
Not Available
23
BUSHING FLANGE
3086382
9999999
Not Available
24
WASHER
3086313
9999999
Not Available
25
WASHER-LOCK
3086286
9999999
Not Available
26
NUT LOCK
3086285
9999999
Not Available
27
GEAR COMPL
3086358
9999999
Not Available
28
GEAR 3RD DRIVEN
3086354
9999999
Not Available
29
RING SNAP
3086363
9999999
Not Available
30
WASHER
3086359
9999999
Not Available
31
GEAR 4TH DRIVEN
3086355
9999999
Not Available
32
GEAR 5TH DRIVEN
3086356
9999999
Not Available
33
GEAR 2ND DRIVEN
3086353
9999999
Not Available
34
CLUTCH
3086357
9999999
Not Available
35
WASHER
3086364
9999999
Not Available
36
BEARING-BALL
3086360
9999999
Not Available
37
SPACER
3086383
9999999
Not Available
38
SPROCKET-DRIVE
3086374
9999999
Not Available
39
SHAFT-COUNTER
3086352
9999999
Not Available
39
SHAFT COUNTER ASM.
3086351
9999999
Not Available
40
COUPLER MALE
3081513
9999999
Not Available
41
BEARING-BALL
3086362
9999999
Not Available
42
PLUG
3086365
9999999
Not Available
43
PIN
3086337
9999999
Not Available
44
PIN
3086338
9999999
Not Available
45
GEAR COMPL
3086335
9999999
Not Available
46
COLLAR
3086336
9999999
Not Available
47
SHAFT-REVERSE
3086334
9999999
Not Available
47
REVERSE SHAFTASM.
3086333
9999999
Not Available

Find the detailed CLUTCH POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
