COOLING SYSTEM for POLARIS SPORTSMAN ACE - A14BH33AJ from 2014

COOLING SYSTEM

1

CORE RADIATOR ASSEMBLY

1240444

1241480

$871,49 Unit Price incl. VAT

2

FAN ASSEMBLY; 11 INCHES; ATV

2410413

$493,49 Unit Price incl. VAT

3

FAN SHROUD

5437845

9999999

Not Available

4

RADIATOR MOUNT BUSHING; LOWER

5410584

$10,49 Unit Price incl. VAT

5

U CLIP; 6.0 MM X 1.0 MM

7547366

$9,44 Unit Price incl. VAT

6

PRESSURE CAP

1240508

$89,24 Unit Price incl. VAT

7

TUBE-COOLANT 3/4 ENG OUT

5138389

9999999

Not Available

8

COOLANT HOSE; FLARED

5414632

9999999

Not Available

9

HOSE-COOLANT FLARED

5414633

$83,99 Unit Price incl. VAT

10

HOSE-COOLANT FRONT

5414634

9999999

Not Available

11

HOSE-COOLANT REAR

5414635

9999999

Not Available

12

HOSE-COOLANT REAR

5414636

9999999

Not Available

13

HOSE-COOLANT FRONT

5414637

9999999

Not Available

14

CONNECTOR TEE 3/4

7052093

$15,74 Unit Price incl. VAT

15

HOSE CLAMP

7080614

$13,64 Unit Price incl. VAT

16

SURGE TANK

5436936

$152,24 Unit Price incl. VAT

17

FITTING 90 DEGREE

7052065

$13,64 Unit Price incl. VAT

18

OVERFLOW CAP

5430743

$10,49 Unit Price incl. VAT

19

CAP PLUG9X(GRN) FLEX TEMP(10)

5433774

$10,49 Unit Price incl. VAT

20

FILLER-REMOTE COOLANT 2FITTING

5438110

9999999

Not Available

21

GASKET

5810279

$4,19 Unit Price incl. VAT

22

FUEL LINE; 1/4 ID

84500031525

Not Available

23

RADIATOR MOUNT; MEDIUM GLOSS BLACK

5256171067

Not Available

24

RADIATOR MOUNT; UPPER; GS BLK

5256172067

Not Available

25

TIE CABLE; 14 IN

7080761

$5,24 Unit Price incl. VAT

26

CLAMP-COOLANT LINES

5258642

9999999

Not Available

27

SPRINGBAND CLAMP; 27/12; GREEN

7080841

$13,64 Unit Price incl. VAT

28

SCREW M6 X 1.0; L-20MM

7516822

$4,19 Unit Price incl. VAT

29

BOLT M6 X 1.0 X 20

7518529

$2,09 Unit Price incl. VAT

30

SCR-TFHFL-M6X1.0X25 ZOD

7519342

$3,14 Unit Price incl. VAT

31

HOSE CLAMP

7080003

$2,09 Unit Price incl. VAT

32

1/4 SAEJ2002;EPDM HOSE;600CM

8450120600

Not Available

33

CLAMP-COOLANT LINES

5258169

9999999

Not Available

34

SCREW

7512084

$2,09 Unit Price incl. VAT

35

SPRING BAND CLAMPS; 32/12

7080843

$7,34 Unit Price incl. VAT

36

TUBE-COOLANT 3/4 ENG IN

5138390

9999999

Not Available

Find the detailed COOLING SYSTEM POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
