1
Engine displacement
500
2
Year
2000
3
Trim
500 XC
4
Parts Catalog
COOLING SYSTEM
5
Parts Diagram
Parts Catalog
SKI
by
STEERING
COOLING SYSTEM
1
2
1
4
4
4
4
4
4
4
5
6
7
7
7
7
7
8
9
10
11
12
13
14
15
16
17
18
19
19
20
21
22
23
1
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
2
FUEL LINE; 1/4 ID
84500031525
Not Available
3
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
4
CLAMP HOSE GRY 35MM.
7080564
9999999
Not Available
5
HOSE ENGINE OUT/BRAKE COOLER
5411662
9999999
Not Available
6
HOSE BRK.COOL/WEARSTRIP
5411380
9999999
Not Available
7
CLAMP HOSE SIL 27MM.
7080562
7080841
$13,64 Unit Price incl. VAT
8
HOSE R.WEARSTRIP COOLER
5411383
9999999
Not Available
9
WEARSTRIP COOLER
2511297
9999999
Not Available
10
RIVET INTERLOCK
7661638
$2,09 Unit Price incl. VAT
11
CLOSE-OFF EXCHANGER
2511304
9999999
Not Available
12
CLAMP 1 IN HOSE
7080585
$7,34 Unit Price incl. VAT
13
POP RIVET(10)
7621425
$2,09 Unit Price incl. VAT
14
HOSECLOSE-OFF/WEAR STRIP COOL
5411260
9999999
Not Available
15
HOSE BYPASS OUT/TEE IN
5411611
9999999
Not Available
16
CLAMP HOSE 1.375 VNL ECOATED
7080908
9999999
Not Available
17
HOSE TEE OUT/TEE IN
5411612
9999999
Not Available
18
HOSETEE/BOTTLE(SN70)
5411481
9999999
Not Available
19
CONNECTOR TEE(1 IN.)
7052087
9999999
Not Available
20
TUBING-CONVOLUTED 1.25 X3
5521510
9999999
Not Available
21
HOSETEE/CENTER COOLER W/SPR
5411616
9999999
Not Available
22
HOSE TEE OUT/PUMP IN
5411613
9999999
Not Available
23
CLAMP HOSE SS
7080560
$20,99 Unit Price incl. VAT

Find the detailed COOLING SYSTEM POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
