1
Engine displacement
600
2
Year
2009
3
Trim
600 IQ TOURING
4
Parts Catalog
HOOD ASM.
5
Parts Diagram
Parts Catalog
FENDER ASM., RH
by
HOOD SCREENS AND HINGE ASM.
HOOD ASM.
1
1
1
2
3
3
4
5
6
6
7
8
8
9
10
11
12
13
14
15
16
1
SCR-10X 5/8 TX PN PLST-243
7518577
$4,19 Unit Price incl. VAT
2
WASHER
7571602
$9,44 Unit Price incl. VAT
3
FOIL
5812758
9999999
Not Available
3
ASM-BRAKE DUCT
2633060
9999999
Not Available
4
ASM-HOOD 600SDI PNT SVC CHERRY
2633757554
Not Available
5
BULB SEAL .375 350 CM
5521697350
Not Available
6
NUT-#10 U-TYPE A(.065-.087)
7670112
$4,19 Unit Price incl. VAT
7
INSTRUMENT POD; GLOSS BLACK
5435789070
Not Available
8
CARTRIDGE FILTER; RIGHT
5435776
9999999
Not Available
8
CARTRIDGE FILTER; LEFT
5435777
9999999
Not Available
9
FOAM FILTER
5812688
$10,49 Unit Price incl. VAT
10
STRAP
5433150
$47,24 Unit Price incl. VAT
11
FOAM-SEAL 35
5812782
9999999
Not Available
12
ASM-HEADLIGHT ACCESS COVER
2633309
9999999
Not Available
13
FOAM-AIRBOX CHIMNEY W/PSA
5813186
9999999
Not Available
14
FOIL-HDLIGHT ACCESS COVER #1
5812937
9999999
Not Available
15
FOIL-HDLIGHT ACCESS COVER#2
5812938
9999999
Not Available
16
FOAM-HEADLIGHT ACCESS COVER
5813094
9999999
Not Available

Find the detailed HOOD ASM. POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
