1
Engine displacement
1000
2
Year
2019
3
Trim
GENERAL 1000 EPS EU TRACTOR ZUG MD
4
Parts Catalog
WIRE HARNESS
5
Parts Diagram
Parts Catalog
WIRE HARNESS
by
ENGINE, AIR INTAKE MANIFOLD
WIRE HARNESS
1
2
3
4
44
6
7
8
12
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
1
2
2
3
4
44
44
6
7
8
12
10
11
12
13
14
1
HARNESS-CHASSIS WINCH ABS
2414561
Not Available
2
CLIP-EDGE 1-3MM THICKNESS
7082428
$9,44 Unit Price incl. VAT
3
FUSE PARK 20 AMP (10)
2434017
4012811
$15,74 Unit Price incl. VAT
4
LABEL FUSE BOX
7188347
Not Available
5
ROUTING CLIP
7081496
$9,44 Unit Price incl. VAT
6
CLIP-ROUTING DIN BOX
7082020
$10,49 Unit Price incl. VAT
7
DIAGNOSTIC COVER WITH CLIP
4012170
4083556
$15,00 Unit Price incl. VAT
8
FUSE 2 AMP ATM BLADE STYLE MINI
401752
Not Available
9
FUSE 5 AMP
4011652
9999999
Not Available
10
SINGLE POLE DOUBLE THROW RELAY
4011284
$68,24 Unit Price incl. VAT
11
GROMMET-USB 3MM 22MM DIA CUT
5416513
Not Available
12
FUSE 5 AMP
4011652
9999999
Not Available
13
LED-PANEL MNT;12V;BLUE
2413217
$99,74 Unit Price incl. VAT
14
FUSE 25 AMP
4011653
$16,79 Unit Price incl. VAT
15
FUSE BOX RELAY
4016819
$68,24 Unit Price incl. VAT
16
FUSE 10 AMP
2434016
$10,49 Unit Price incl. VAT
17
FUSE-MINI BLADE;15 AMP
2410280
4010859
$15,74 Unit Price incl. VAT
18
COIL GROUND JUMPER
4014422
$62,99 Unit Price incl. VAT
19
BRKT-COIL MOUNT
5260553
$31,49 Unit Price incl. VAT
20
COIL MOUNT SPACER
5436577
$7,34 Unit Price incl. VAT
21
BOLT M6 X 1.0 X 20
7518529
$2,09 Unit Price incl. VAT
22
HARNESS-CHASSIS ADAPTER ACCY
2413521
9999999
Not Available
23
SCR-M6X1.0X40 HX/SOC/CP-B
7518780
$7,34 Unit Price incl. VAT
24
NYLOCK FLANGE NUT; 6 MM
7547274
7548027
$3,14 Unit Price incl. VAT
25
BLOCK-TERMINAL 6 POS
4016007
$68,24 Unit Price incl. VAT
26
SCR-10-24X3/4 PH/TX/TRI-SEMS Y (10)
7518196
$2,09 Unit Price incl. VAT
27
NUT-HXFLGHD M6 SERRATED
7547270
$7,34 Unit Price incl. VAT
28
NO START ELECTRIC CONTROL MODULE (ECM)
4014125
$1 123,49 Unit Price incl. VAT
29
SCR-#10X1/2-HI/LO-PN-T25 TRX-M
7519091
$6,29 Unit Price incl. VAT
30
HARNESS-BOX TR
2413864
Not Available
31
SCREW
7512025
$9,44 Unit Price incl. VAT
32
RELAY SOLID STATE 9A
4012829
4081742
$141,74 Unit Price incl. VAT
33
HEX FLANGE SCREW; 6 MM X 1.0 MM X 20 MM
7519121
$7,34 Unit Price incl. VAT
34
NUT-M6X1.0 FLG-NYLOC-OLIVE D
7547339
$2,09 Unit Price incl. VAT
35
CAB ELECTRICAL GROMMET
5414440
$13,64 Unit Price incl. VAT
36
BRKT-RELAY INNER MOUNT BLK
5267577458
Not Available
37
BRKT-RELAY OUTER MOUNT BLK
5267578458
Not Available
38
SCREW
7517704
$13,64 Unit Price incl. VAT
39
NYLOK NUT
7546703
$2,09 Unit Price incl. VAT
40
JUMPER TRAILER SOCKET CONNECT
4017417
Not Available
41
CABLE TIE
7080138
$5,24 Unit Price incl. VAT
42
VOLTAGE REGULATOR
4016868
$246,74 Unit Price incl. VAT
43
SPEED SENSOR;WHEEL
4016870
Not Available
44
ROUTING CLIP
7081496
$9,44 Unit Price incl. VAT
45
STRAP-PANDUIT DBL LOOP 260MM
7081916
$9,44 Unit Price incl. VAT
46
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
47
PULSE MOUNT BRACKET; MATTE BLACK
5266257458
Not Available
48
SCR-TFHFL-M6X1.0X25 ZOD
7519342
$3,14 Unit Price incl. VAT
49
CLIP-EDGE SIDE W/STRAP
7081876
9999999
Not Available
50
COIL-EFI
4010425
2876049
$451,49 Unit Price incl. VAT

Find the detailed WIRE HARNESS POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
