1
Engine displacement
300
2
Year
1994
3
Trim
300 6X6 - W948730
4
Parts Catalog
FRONT WHEEL ASSEMBLY 6X6 300 W948730 (4926792679B005)
5
Parts Diagram
Parts Catalog
AIR BOX 6X6 300 W948730 (4926792679A014)
by
FRONT BRAKE 6X6 300 W948730 (4926792679B006)
FRONT WHEEL ASSEMBLY 6X6 300 W948730 (4926792679B005)
1
2
3
4
5
6
7
8
9
10
11
12
12
13
13
14
15
16
17
18
19
20
21
22
23
24
1
ROLL CAGE
3250028
9999999
Not Available
2
ROLL
3250010
9999999
Not Available
3
SPRING; GARTER
3250022
9999999
Not Available
4
SPACER
3250026
9999999
Not Available
5
CAM
3250027
9999999
Not Available
6
BOLT
7515321
9999999
Not Available
7
DISC BRAKE
5211325
9999999
Not Available
8
HUB SEAL; FRONT
3610019
$68,24 Unit Price incl. VAT
9
ARMATURE PLATE
5211148
$52,49 Unit Price incl. VAT
10
KEY
7721115
9999999
Not Available
11
CLUTCH ASMF.HUBELEC/MECH.
1520190
9999999
Not Available
12
TAPER ROLL CONE BEARING
3554506
$54,59 Unit Price incl. VAT
13
TAPER ROLL CUP BEARING
3554507
$54,59 Unit Price incl. VAT
14
HUB ASM;W/BRG.RACE
1520182
9999999
Not Available
15
STUD
7515523
$5,76 Unit Price incl. VAT
16
MAGNETIC DRAIN PLUG
7052045
$26,24 Unit Price incl. VAT
17
WRANGLER SPORT 22-800-10NHS
5410480
9999999
Not Available
18
RIM VALVE
1525017
$12,59 Unit Price incl. VAT
19
RIM FRT (SILVER)
1520175117
Not Available
20
WASHER
5211101
9999999
Not Available
21
NUT RH THREAD
7543201
9999999
Not Available
22
O-RING
5410470
$4,19 Unit Price incl. VAT
23
CAP HUB
5431367
9999999
Not Available
24
FLANGED NUT LOCK(10)
7542459
$3,14 Unit Price incl. VAT

Find the detailed FRONT WHEEL ASSEMBLY 6X6 300 W948730 (4926792679B005) POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
