1
Engine displacement
1000
2
Year
2018
3
Trim
RZR XP 1000
4
Parts Catalog
REAR RACK AND FENDERS
5
Parts Diagram
Parts Catalog
REAR BUMPER
by
DRIVE TRAIN, FRONT GEARCASE
REAR RACK AND FENDERS
1
1
1
2
2
2
3
4
5
6
6
7
7
8
8
8
9
10
11
12
13
13
14
15
16
17
17
18
19
19
19
20
20
21
22
23
24
25
26
27
27
28
29
30
31
1
REAR LEFT HAND FENDER ASM PEARL BLACK
2635123666
Not Available
1
FENDER ASM LEFT SIDE WHITE LIGHTNING
2635123599
Not Available
1
ASM-FNDR PNT RR CLIP LH ST.BLK
2635123464
Not Available
2
REAR RIGHT HAND FENDER ASM PEARL BLACK
2635126666
Not Available
2
FENDER; REAR; RIGHT HAND; STEALTH BLACK
2635126464
Not Available
2
FENDER REAR RIGHT SIDE WHITE LIGHTNING
2635126599
Not Available
3
DASH TRIM CLIP
7519806
$7,34 Unit Price incl. VAT
4
REAR LEFT FENDER FLARE; GLOSS BLACK
5439762070
Not Available
5
REAR RIGHT FENDER FLARE; GLOSS BLACK
5439763070
Not Available
6
BOLT
7519650
$7,34 Unit Price incl. VAT
7
U-TYPE NUT; M6-1.0
7547674
$2,09 Unit Price incl. VAT
8
TUFLOK RIVET
7661855
$2,09 Unit Price incl. VAT
9
LEFT HAND FROG SKINZ BEZEL ASSEMBLY
2635658
$204,74 Unit Price incl. VAT
10
SCR-TXPH-#14X3/4 HI/LO CLR
7519290
$7,34 Unit Price incl. VAT
11
AIR INTAKE BEZEL; LEFT
5451620070
Not Available
12
INTAKE COVER WITH MESH
2635659
$204,74 Unit Price incl. VAT
13
REAR FASCIA ASM GLOSS BLK INCLUDES DECAL
2635073070
Not Available
13
FASCIA W/ DECAL ASM REAR GLOSS BLACK
2636319070
Not Available
14
AIR INTAKE BEZEL; RIGHT; GLOSS BLACK
5451621070
Not Available
15
BOX PLUNGER LATCH
5139009
$25,19 Unit Price incl. VAT
16
FASCIA BRACKET; REAR; BLACK
5257790329
Not Available
17
LEFT SIDE BED BOX
5454271
$472,49 Unit Price incl. VAT
17
LEFT SIDE BED BOX
5454272
$488,24 Unit Price incl. VAT
18
RZR XP1000 REAR BOX SECTION; RIGHT SIDE
5454270
$472,49 Unit Price incl. VAT
19
COVER PLASTIC;REAR ROP;LH;BLK
5453087070
Not Available
19
COVER-PLASTIC REAR ROP LH BLK
5451622070
Not Available
19
SHOCK PANEL RESERVOIR; LEFT; GLOSS BLACK
5452043070
Not Available
20
COVER; REAR; RIGHT; PLASTIC; GLOSS BLACK
5451623070
Not Available
20
PANEL-SHOCK RESERVOIR RH BLK
5452044070
Not Available
21
KNOB 6 MM X 1.0 MM
7081619
$29,39 Unit Price incl. VAT
22
SCREW
7512026
$2,09 Unit Price incl. VAT
23
NUT-M6X1.0 FLG-NYLOC-OLIVE D
7547339
$2,09 Unit Price incl. VAT
24
FLAT WASHER
7555859
$2,09 Unit Price incl. VAT
25
WASHER NYLON
7555916
$3,14 Unit Price incl. VAT
26
BOLT RETAINER; 1/4 -20
7670154
$2,09 Unit Price incl. VAT
27
ASM-PANEL-BOX ACCESS
2636783
9999999
Not Available
27
ACCESS PANEL BOX ASSEMBLY
2636746
$194,24 Unit Price incl. VAT
28
SEAT LATCH LEVER
5437121
$9,44 Unit Price incl. VAT
29
ACCESS BOX PANEL
5454273
9999999
Not Available
30
COVER PLATE LATCH; GLOSS BLACK
5450510070
Not Available
31
SEAT LATCH SPRING
7081466
$57,74 Unit Price incl. VAT

Find the detailed REAR RACK AND FENDERS POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
