DRIVE TRAIN, MAIN GEARCASE for POLARIS SPORTSMAN TOURING 570 EPS EU 3PC from 2022

DRIVE TRAIN, GEAR SELECTOR

DRIVE TRAIN, MAIN GEARCASE MOUNTING

ASM-TRANSMISSION DIFF TURF

1334090

$4 866,74 Unit Price incl. VAT

TRIPLE LIP SEAL; 40 X 70 X 7

3234300

$57,74 Unit Price incl. VAT

COVER; LEFT

3234260

$803,24 Unit Price incl. VAT

BALL BEARING; 50 X 80 X 10

3234275

$47,24 Unit Price incl. VAT

CHAIN

3234057

$519,74 Unit Price incl. VAT

CASE-RH MACH

3236313

$960,74 Unit Price incl. VAT

BEARING

3233018

$47,24 Unit Price incl. VAT

SPROCKET; 19 TOOTH

3234060

$451,49 Unit Price incl. VAT

OIL DEFLECTOR

3234061

3239943

$52,49 Unit Price incl. VAT

SCREW

3233749

$10,49 Unit Price incl. VAT

GEAR OUTPUT

3234062

$493,49 Unit Price incl. VAT

RING-RETAINING

3233699

$13,64 Unit Price incl. VAT

SCREW TAPPINGHEXHEAD1/4-20X.75

3234247

$10,49 Unit Price incl. VAT

COVER-CENTER DRIVE BEARING

3234063

$62,99 Unit Price incl. VAT

RETAINING RING

3233364

$12,59 Unit Price incl. VAT

SHIM; 1.700 X 1.385

3234271

$47,24 Unit Price incl. VAT

BALL BEARNING

3234065

$80,84 Unit Price incl. VAT

PINION; 13T CENTER DRIVE

3234263

$818,99 Unit Price incl. VAT

RETAINING RING

3234067

$14,69 Unit Price incl. VAT

WASHER

3233176

$17,84 Unit Price incl. VAT

HELICAL GEAR; 35 TOOTH

3236032

$262,49 Unit Price incl. VAT

BEARING; NEEDLE

3233009

$68,24 Unit Price incl. VAT

WASHER

3233855

$19,94 Unit Price incl. VAT

DOG; L/P

3234257

$283,49 Unit Price incl. VAT

ENGAGEMENT DOG 6 FACE

3234258

$178,49 Unit Price incl. VAT

RETAINING RING

3233306

$9,44 Unit Price incl. VAT

THRUST WASHER; 1.300 X .995 X .065

3234248

$17,84 Unit Price incl. VAT

SPROCKET; 6-FACE; 38 TOOTH

3234290

$283,49 Unit Price incl. VAT

REVERSE SHAFT; 26 TOOTH

3234280

$488,24 Unit Price incl. VAT

GEAR; 33T 6-FACE

3234291

$325,49 Unit Price incl. VAT

SHIFT COLLAR

3234073

$57,74 Unit Price incl. VAT

PLATE-PARK 12 FACE

3233915

$73,49 Unit Price incl. VAT

BEARING; BALL; 17 X 40 X 12

3234274

$47,24 Unit Price incl. VAT

SEAL

3234851

$68,24 Unit Price incl. VAT

BEARING

3233019

$54,59 Unit Price incl. VAT

SHAFT-INPUT HELICAL 39T

3235526

$451,49 Unit Price incl. VAT

CHAIN; .25 P X .40 W X 50 L

3234264

$188,99 Unit Price incl. VAT

SPRING COMPRSSN.54ODX.44IDX.05

3234277

$26,24 Unit Price incl. VAT

SHIFT FORK

3234077

$335,99 Unit Price incl. VAT

COMPRESSION SPRING

3234078

$47,24 Unit Price incl. VAT

RAIL-SHIFT SHAFT

3234079

3235542

$52,49 Unit Price incl. VAT

DOWEL PIN

3233432

$13,64 Unit Price incl. VAT

TORISON SPRING

3233431

$47,24 Unit Price incl. VAT

CHAIN TENSIONER CAM

3233434

$26,24 Unit Price incl. VAT

CHAIN TENSIONER SHOE

3233433

$62,99 Unit Price incl. VAT

DRUM SHIFT

3234360

$335,99 Unit Price incl. VAT

SECTOR GEAR; 31 TOOTH CUT TO 11 TOOTH

3233832

$68,24 Unit Price incl. VAT

SHIFT SHAFT

3233831

$115,49 Unit Price incl. VAT

O-RING

3233828

$12,59 Unit Price incl. VAT

DETENT PAWL

3233829

$68,24 Unit Price incl. VAT

COMPRESSION DETENT SPRING

3234578

$26,24 Unit Price incl. VAT

GEARCASE COVER

3234188

$209,99 Unit Price incl. VAT

BELLCRANK 510 HOLE 92 DEGREE

3234584

$52,49 Unit Price incl. VAT

NUT-LOCK HEX FLANGE NYLON 5/16

3233961

$5,24 Unit Price incl. VAT

GEAR POSITION SWITCH PIN

7661999

$220,49 Unit Price incl. VAT

RETAINING RING

3233834

$19,94 Unit Price incl. VAT

SECTOR GEAR; 16 TOOTH

3233839

$68,24 Unit Price incl. VAT

TRANSMISSION SPEED SENSOR

4013908

4082135

$204,74 Unit Price incl. VAT

DETENT STAR

3233909

$52,49 Unit Price incl. VAT

O-RING

3233836

$12,59 Unit Price incl. VAT

SNORKEL; 13 TOOTH

3234262

$608,99 Unit Price incl. VAT

BALL BEARING

3233265

$68,24 Unit Price incl. VAT

RING RETAINING BSCEXTERNAL0.84

3234336

$10,49 Unit Price incl. VAT

SNORKLE TUBE

3234278

$188,99 Unit Price incl. VAT

SCREW-TORX TRUSS HD

3234086

$10,49 Unit Price incl. VAT

SHIM 1.180 X .995(9)

3234272

$68,24 Unit Price incl. VAT

SNAP RING

3233106

$10,49 Unit Price incl. VAT

TRIPLE LIP SEAL; 25 X 80 X 10

3234113

$68,24 Unit Price incl. VAT

TUBE-VENT 90-1/4 HOSE

3234230

$19,94 Unit Price incl. VAT

SCR-TAPPING HEX WASHER HD 5/16

3234114

$13,64 Unit Price incl. VAT

PIN DOWEL 5/16 X 1.0

3234244

$13,64 Unit Price incl. VAT

HEX PLUG W/ O-RING; HOLLOW

3233794

$31,49 Unit Price incl. VAT

COMPRESSION SPRING

3234089

$52,49 Unit Price incl. VAT

RETAINING RING

3234090

$19,94 Unit Price incl. VAT

CUP WASHER

3234091

$17,84 Unit Price incl. VAT

RING RETAININGBASICINTRNL2.047

3234269

$17,84 Unit Price incl. VAT

SHIM; 2.040 OD X 1.630 ID

3234273

$26,24 Unit Price incl. VAT

ENGAGEMENT DOG

3234928

$136,49 Unit Price incl. VAT

TORSION RETURN SPRING

3234276

$16,79 Unit Price incl. VAT

FORK; PIVOT SHIFT REAR DIFF

3234285

$120,74 Unit Price incl. VAT

GEAR SUBASSEMBLY; 36 TOOTH; SIDE

3234363

$435,74 Unit Price incl. VAT

CARRIER SUBASSEMBLY

3234470

$509,24 Unit Price incl. VAT

GEAR; 36 TOOTH DISCONNECT SUBASM; SIDE

3234362

$561,74 Unit Price incl. VAT

GEAR SUBASSEMBLY

3234469

$136,49 Unit Price incl. VAT

DOWEL PIN; 10 X 45

3234238

$25,19 Unit Price incl. VAT

410876 - COVER SUBASSEMBLY

3234471

$404,24 Unit Price incl. VAT

SCREW; HH; 5/16-24X1.5

3234267

$13,64 Unit Price incl. VAT

SOLENOID

3235478

$545,99 Unit Price incl. VAT

WASHER FENDER.256 X 1.00 X.047

3234268

$13,64 Unit Price incl. VAT

SUBASSEMBLY-COVER LH PDS

3236312

$908,24 Unit Price incl. VAT

CARRIER-SUBASM LOCKING DIFF 1

3235594

$824,24 Unit Price incl. VAT

BRKT-MOUNT(430592)

3235350

$16,79 Unit Price incl. VAT

BEARING; NEEDLE

3233103

$54,59 Unit Price incl. VAT

SPACER

3235243

$17,84 Unit Price incl. VAT

O-RING

3233840

$20,99 Unit Price incl. VAT

PLUG; .75 HOLLOW HEX MAGNETIC

3234529

3233794

$31,49 Unit Price incl. VAT

Find the detailed DRIVE TRAIN, MAIN GEARCASE POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
