COOLING SYSTEM for POLARIS 600 SWITCHBACK PRO R / ES from 2014

COOLING SYSTEM

1

COOLANT BOTTLE WELD

2521004

9999999

Not Available

2

CAP-PRESSURE

1240169

1240300

$73,49 Unit Price incl. VAT

3

RIVET

7621472

$2,09 Unit Price incl. VAT

4

SPRINGBAND CLAMP; 35/12

7080844

$19,94 Unit Price incl. VAT

5

HOSE-BOTTLE/TNL CLR RETURN

5414003

9999999

Not Available

6

CLAMP SPRINGBAND 29/12 BLK

7080842

$13,64 Unit Price incl. VAT

7

HOSE-CTR CLR/TNL CLR SUPPLY

5414004

9999999

Not Available

8

WELD-WEAR STRIP COOLER 136 LH

1240604

9999999

Not Available

8

WELD-WEAR STRIP COOLER 136 RH

1240605

9999999

Not Available

9

RIVET 4.8 MM

7661973

$2,09 Unit Price incl. VAT

10

WELD-COOLER BULKHEAD

1240707

9999999

Not Available

11

HOSE-ENGINE/CTR COOLER SUPPLY

5413862

9999999

Not Available

12

CLAMP HOSE 1 IN NYLON

7080653

$9,44 Unit Price incl. VAT

13

HEX FLANGE SCREW; 5 MM X .80 MM X 8 MM

7518045

9999999

Not Available

14

RIVET

7661637

$2,09 Unit Price incl. VAT

15

FITTING 1/2ID.HOSE

7052222

$41,99 Unit Price incl. VAT

16

HOSE-BULKHEAD/ENGINE RETURN

5413706

9999999

Not Available

17

GROMMET-16.5X28.5X9.5MM

5413710

9999999

Not Available

18

TUBE-ENGINE/RADIATOR

5335679

9999999

Not Available

19

HOSE-TUBE RADIATOR OUT

5413508

9999999

Not Available

20

RADIATOR ASSEMBLY; SNOW

1240403

9999999

Not Available

21

HOSE-TUBE RADIATOR IN

5413507

9999999

Not Available

22

HOSE-ENGINE/BULKHEAD SUPPLY

5413857

9999999

Not Available

23

NYLOC OLIVE NUT; 8 MM X 1.25 MM

7547332

$7,34 Unit Price incl. VAT

24

SCR-M8X1.25X40 10.9 HX/FL ZOD

7518954

$10,49 Unit Price incl. VAT

25

CLAMP HOSE SS

7080560

$20,99 Unit Price incl. VAT

26

BOTTLE/ENGINE HOSE

5414044

$178,49 Unit Price incl. VAT

27

CONNECTOR TEE 3/4

7052093

$15,74 Unit Price incl. VAT

28

THERMOSTAT-50C TBYS ADH

7052376

9999999

Not Available

28

O-RING LIP SEAL

5411521

9999999

Not Available

29

HOSE-ENGINE OUT/T IN

5413858

9999999

Not Available

30

HOSE-BYPASS

5413859

9999999

Not Available

31

CLAMP SPRING BAND

7081692

$8,39 Unit Price incl. VAT

32

HOSE CLAMP

7080534

$3,14 Unit Price incl. VAT

33

HOSE-BOTTLE/TBODY OUT

5414324

9999999

Not Available

34

FUEL LINE; 1/4 ID

84500031525

Not Available

35

HOSE-TUNNEL COOLER/MFC

5413973

9999999

Not Available

36

CLAMP SPRINGBAND

7081693

$8,39 Unit Price incl. VAT

37

MID FLAP COOLER WELD

1240579

9999999

Not Available

38

SCR-M8X1.25X70 8.8 HH ZOD

7518992

9999999

Not Available

39

WASHER-.344X.688X.063 FL-ZOD

7556524

$1,56 Unit Price incl. VAT

40

SPACER-COOLER

5137860

9999999

Not Available

41

HEX FLANGE SCREW; 8 MM X 1.25 MM X 40 MM

7519267

$7,34 Unit Price incl. VAT

42

WEARSTRIP-MACH 136

5137679

9999999

Not Available

43

RIVET-POP

7621220

9999999

Not Available

Find the detailed COOLING SYSTEM POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
