FUEL SYSTEM, FUEL TANK ASM. for POLARIS SLINGSHOT / SL from 2015

ENGINE, TIMING CHAIN AND RELATED PARTS

OWNERS MANUAL/TOOL KIT

FUEL SYSTEM, FUEL TANK ASM.

1

FUEL TANK WELD

1018856

$3 863,99 Unit Price incl. VAT

2

FUEL CAP; NON VENTED

2521278

$89,24 Unit Price incl. VAT

3

NUT-FILLER NECK

5435156

$9,44 Unit Price incl. VAT

4

FILLER NECK FUEL CAP

2521383

5465067

$68,24 Unit Price incl. VAT

5

CLAMP BAND; NARROW

7080413

$5,76 Unit Price incl. VAT

6

HOSE-FUEL FILL

5414709

$115,49 Unit Price incl. VAT

7

HEX FLANGE HEAD SCREW; 10 MM X 25 MM

7518908

$3,14 Unit Price incl. VAT

8

STRAP-FUEL TANK

5260625

9999999

Not Available

9

PAD-FUEL TANK;MNT BRKT

5813873

$36,74 Unit Price incl. VAT

10

HOSE-FUEL FILL OVERFLOW

5414578

5526651

Not Available

11

TANK FUEL LINE

5414454

9999999

Not Available

12

PAD-FUEL TANK; FRAME TUBE

5814171

$36,74 Unit Price incl. VAT

13

CABLE TIE

7080138

$5,24 Unit Price incl. VAT

14

LINE-FUEL FRAME

8450133

9999999

Not Available

15

CLIP-CABLE TIE

5439713

$9,44 Unit Price incl. VAT

16

SCR-M6X1X14 PN/TX TRI-LOB

7518914

$6,29 Unit Price incl. VAT

17

CABLE TIE

7080138

$5,24 Unit Price incl. VAT

18

ROUTING CLIP

7081496

$9,44 Unit Price incl. VAT

19

LINE-FUEL ENGINE

5414455

9999999

Not Available

20

MASON JAR NUT

5437138

$68,24 Unit Price incl. VAT

21

GASKET-PFA RIBBED

5413451

$20,99 Unit Price incl. VAT

22

FUEL PUMP

2521242

$839,99 Unit Price incl. VAT

23

INSERT-FUEL FILL

5450366

$68,24 Unit Price incl. VAT

24

SCR-HXBH-M8X1.25X55 10.9 ZY3

7520293

$10,49 Unit Price incl. VAT

25

NYLOC OLIVE NUT; 8 MM X 1.25 MM

7547332

$7,34 Unit Price incl. VAT

26

REAR BRACE; SUB FRAME; BLACK

5260730329

Not Available

Find the detailed FUEL SYSTEM, FUEL TANK ASM. POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
