1
Engine displacement
570
2
Year
2023
3
Trim
RANGER SP 570 NORTHSTAR EDITION
4
Parts Catalog
STEERING
5
Parts Diagram
Parts Catalog
REFERENCES, TOOL KIT AND OWNERS MANUALS
by
SUSPENSION, A-ARM AND STRUT MOUNTING
STEERING
1
2
3
4
5
5
6
7
8
8
9
9
10
11
12
13
13
13
14
15
16
17
18
18
19
20
21
22
23
23
23
24
25
26
1
ASM-TILT STEERING RVTD M10 BLK
1830042458
Not Available
2
STEERING BUSHING
7556675
$24,14 Unit Price incl. VAT
3
WHEEL-STEERING
1830011
$246,74 Unit Price incl. VAT
4
CAP-STEERING WHEEL
5417672
$62,99 Unit Price incl. VAT
5
HEX FLANGE SCREW; 8 MM X 1.25 MM X 35 MM
7519052
$3,14 Unit Price incl. VAT
6
STEERING BEARING
3514686
$16,79 Unit Price incl. VAT
7
OIL LOCKING SHOCK ASSEMBLY
7044098
$178,49 Unit Price incl. VAT
8
BOLT-SHOULDER M8-15 M6X1.0-BLK
7519980
$13,64 Unit Price incl. VAT
9
NYLOK NUT
7546703
$2,09 Unit Price incl. VAT
10
ASM-GEARBOX STEERING
1801252
$955,49 Unit Price incl. VAT
11
SCR-HXFL-M8X1.25X95 10.9 ZFB
752133295
Not Available
12
HEX FLANGE BOLT; 8 MM X 1.25 MM X 20 MM
7518702
$7,34 Unit Price incl. VAT
13
NYLOC OLIVE NUT; 8 MM X 1.25 MM
7547332
$7,34 Unit Price incl. VAT
14
ASM-POWER STEERING;2.5T;250K
2416569
$3 538,49 Unit Price incl. VAT
15
POWER STEERING BRACKET; BLACK
5258708329
Not Available
16
SCREW
7517281
$13,64 Unit Price incl. VAT
17
BOLT-M8X1.25X25 HXFLG-OLIVE D
7518514
$3,14 Unit Price incl. VAT
18
HEX FLANGE BOLT OLIVE 10MMX1.25MMX20MM
7518558
$7,34 Unit Price incl. VAT
19
STEERING SHAFT; UPPER
1824164
$325,49 Unit Price incl. VAT
20
SHAFT-STEERING LWR W/JNT EPAS
1830020
$362,24 Unit Price incl. VAT
21
SCR-HXFL-M8X1.25X40 10.9 ZFB
752133240
Not Available
22
NUT-NY INS;M10X1.5;HEX;ZINC;YW
7547385
$2,09 Unit Price incl. VAT
23
NYLOC NUT
7547333
$3,14 Unit Price incl. VAT
24
NUT-HEX-M16X2 8 ZC NYL
7547506
$7,34 Unit Price incl. VAT
25
BOLT-M10X1.25X130 HXFLG-OLIVED
7518665
$25,19 Unit Price incl. VAT
26
SCR-HXFL-M10X1.5X40 10.9 ZFB
752133340
Not Available

Find the detailed STEERING POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
