COOLING SYSTEM for POLARIS M1400 GAS - L15U2NAGFA/MA from 2015

COOLING SYSTEM

1

SURGE TANK

5436936

$152,24 Unit Price incl. VAT

2

FITTING 90 DEGREE

7052065

$13,64 Unit Price incl. VAT

3

FUEL LINE; 1/4 ID

84500031525

Not Available

4

BRKT-SURGE TANK

5254763

$10,49 Unit Price incl. VAT

5

OVERFLOW CAP

5430743

$10,49 Unit Price incl. VAT

6

CAP PLUG9X(GRN) FLEX TEMP(10)

5433774

$10,49 Unit Price incl. VAT

7

GASKET

5810279

$4,19 Unit Price incl. VAT

8

SCREW

7512084

$2,09 Unit Price incl. VAT

9

RADIATOR ASSEMBLY

1240721

$913,49 Unit Price incl. VAT

10

PRESSURE CAP

1240300

$73,49 Unit Price incl. VAT

11

RADIATOR-FLAT

1240720

1240721

$913,49 Unit Price incl. VAT

12

GROMMET AND INSERT ASSEMBLY

5413155

$7,34 Unit Price incl. VAT

13

VALVE-PLASTIC RAD/COOLER DRAIN

7052410

$52,49 Unit Price incl. VAT

14

FAN ASSEMBLY

2410865

$289,79 Unit Price incl. VAT

15

RADIATOR MOUNT BUSHING; LOWER

5410584

$10,49 Unit Price incl. VAT

16

FAN SHROUD

5436852

9999999

Not Available

17

SPRING BAND CLAMPS; 32/12

7080843

$7,34 Unit Price incl. VAT

18

CLAMP-CONSTANT TENSION;16-27

7081415

$13,64 Unit Price incl. VAT

19

SCREW M6 X 1.0; L-20MM

7516822

$4,19 Unit Price incl. VAT

20

SCR-M6X1X40 TR/TX-M

7519001

$7,34 Unit Price incl. VAT

21

SCR-TFHFL-M6X1.0X25 ZOD

7519342

$3,14 Unit Price incl. VAT

22

U CLIP; 6.0 MM X 1.0 MM

7547366

$9,44 Unit Price incl. VAT

23

TUBE-COOLANT 1 IN

5139592

9999999

Not Available

24

RADIATOR HOSE; LOWER

5414977

$89,24 Unit Price incl. VAT

25

ENGINE OUTLET HOSE; REAR

5415051

9999999

Not Available

26

HOSE-ENGINE IN;REAR

5415052

9999999

Not Available

27

RADIATOR HOSE; UPPER

5415269

$99,74 Unit Price incl. VAT

28

COOLANT TUBE BRACKET

5451221

$16,79 Unit Price incl. VAT

29

SPRING BAND CLAMPS; 32/12

7080843

$7,34 Unit Price incl. VAT

30

SCREW

7512026

$2,09 Unit Price incl. VAT

Find the detailed COOLING SYSTEM POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
