1
Engine displacement
900
2
Year
2013
3
Trim
RZR 4 XP 900 PS INTL - R13XT9EFX
4
Parts Catalog
DRIVE TRAIN, MAIN GEARCASE
5
Parts Diagram
Parts Catalog
DRIVE TRAIN, GEAR SELECTOR
by
IGNITION
DRIVE TRAIN, MAIN GEARCASE
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
38
39
40
1
ASM-GEARCASE COMPLETE DIFF
1333063
9999999
Not Available
2
PLUG; M18 X 1.5
3234755
$52,49 Unit Price incl. VAT
3
SOCKET HEAD W/ MAG PLUG 18 MM X 1.5 MM
3234756
$57,74 Unit Price incl. VAT
4
HEX HEAD FLANGE SCREW 8MMX1.25MMX30MM
3234898
$17,84 Unit Price incl. VAT
5
SCREW
3235206
$13,64 Unit Price incl. VAT
6
SCREW
3235207
$19,94 Unit Price incl. VAT
7
SOCKET HEAD SCREW; 6 MM X 1 MM X 18 MM
3235332
$7,34 Unit Price incl. VAT
8
HEXFLANGE NUT; NYLON; 8 MM X 1.25 MM
3235210
$14,69 Unit Price incl. VAT
9
PIN; DOWEL; 6 X 20
3234330
$13,64 Unit Price incl. VAT
10
SPRING-SLOTTED PIN;6MM
7043746
$15,74 Unit Price incl. VAT
11
RETAINING RING
3233834
$19,94 Unit Price incl. VAT
12
THRUST WASHER; .446 X .88 X .025
3234642
$19,94 Unit Price incl. VAT
13
BALL BEARING
3233268
$88,19 Unit Price incl. VAT
14
SPRING COMPRSSN.54ODX.44IDX.05
3234277
$26,24 Unit Price incl. VAT
15
COMPRESSION SPRING
3233830
$19,94 Unit Price incl. VAT
16
SPRING WASHER
3235327
$17,84 Unit Price incl. VAT
17
GEARCASE COVER
3234188
$209,99 Unit Price incl. VAT
18
CASE WITH DIFFERENTIAL SUBASSEMBLY; LEFT
3235468
9999999
Not Available
19
CASE SUBASSEMBLY; RIGHT
3235446
9999999
Not Available
20
SECTOR GEAR; 16 TOOTH
3233839
$68,24 Unit Price incl. VAT
21
SECTOR GEAR; 31 TOOTH CUT TO 11 TOOTH
3233832
$68,24 Unit Price incl. VAT
22
ROLLER PAWL
3235452
$68,24 Unit Price incl. VAT
23
DETENT STAR
3235453
9999999
Not Available
24
PARK PLATE
3235456
$73,49 Unit Price incl. VAT
25
BELLCRANK
3235227
$52,49 Unit Price incl. VAT
26
TUBE-VENT 90-1/4 HOSE
3234230
$19,94 Unit Price incl. VAT
27
SHIFT SHAFT
3235238
$68,24 Unit Price incl. VAT
28
BRACKET; MOUNT; REAR
3235239
$73,49 Unit Price incl. VAT
29
REAR MOUNT BRACKET
3235351
$89,24 Unit Price incl. VAT
30
SPACER
3235243
$17,84 Unit Price incl. VAT
31
SOLENOID
3235478
$545,99 Unit Price incl. VAT
32
GEAR POSITION SWITCH PIN
7661999
$220,49 Unit Price incl. VAT
33
O-RING
3233836
$12,59 Unit Price incl. VAT
34
O-RING
3234302
$13,64 Unit Price incl. VAT
35
O-RING
3233828
$12,59 Unit Price incl. VAT
36
VITON TRIPLE LIP SEAL
3234892
$68,24 Unit Price incl. VAT
37
SEAL INPUT TPL VITON (560373)
3235466
$57,74 Unit Price incl. VAT
38
VITON TRIPLE LIP SEAL; 40 X 70 X 7
3235052
$57,74 Unit Price incl. VAT
39
TRANSMISSION SPEED SENSOR
4013908
4082135
$204,74 Unit Price incl. VAT
40
BRKT-MOUNT(430592)
3235350
$16,79 Unit Price incl. VAT

Find the detailed DRIVE TRAIN, MAIN GEARCASE POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
