REAR SUSPENSION for POLARIS SPORTSMAN TOURING EPS 850 - A12DN8EAF/EAH/EAR/EAW from 2012

REAR SUSPENSION

1

HEX HEAD FLANGE BOLT 10MM X 1.5MM X140MM

7518467

$10,49 Unit Price incl. VAT

2

HEX FLANGE NUT; 10 MM X 1.5 MM

7547313

$2,09 Unit Price incl. VAT

3

CONTROL ARM BUSHING

5436798

$4,19 Unit Price incl. VAT

4

WELD-UCA REAR RH CLOUD SILVER

1017217385

Not Available

4

CONTROL ARM WELD; REAR; LEFT

1017216067

Not Available

4

CONTROL ARM WELD; REAR; UPPER; RIGHT

1017217067

Not Available

4

CONTROL ARM WELD REAR UPPER LEFT CLD SLV

1017216385

Not Available

5

FITTING LUBRICATION THREADED(1

7080433

$2,09 Unit Price incl. VAT

6

A-ARM SHAFT

5137346

$31,49 Unit Price incl. VAT

7

BOLT 10 MM X 1.5 MM X 85

7518466

$9,44 Unit Price incl. VAT

8

WELD-LCA REAR RH CLOUD SILVER

1018216385

Not Available

8

WELD-LCA REAR LH BLK

1018215067

Not Available

8

WELD-LCA REAR RH BLK

1018216067

Not Available

8

WELD-LCA REAR LH CLOUD SILVER

1018215385

Not Available

9

HEX HEAD FLANGE BOLT; 1.5 MM X 130 MM

7518675

$10,49 Unit Price incl. VAT

10

PIVOT SHAFT; 104.9 MM

5137590

$16,79 Unit Price incl. VAT

11

LOWER CONTROL ARM A ARM SHAFT

5136473

5145086

$68,24 Unit Price incl. VAT

12

CONTROL ARM BUSHING; LOWER; .75 IN

5437651

$12,59 Unit Price incl. VAT

13

PIVOT SHAFT; 210.27 MM; ZINC YELLOW

5137594

$16,79 Unit Price incl. VAT

14

A-ARM BUSHING; LONG; 102.36 MM

5436973

$9,44 Unit Price incl. VAT

15

HEX HEAD FLANGE BOLT 10MM X 1.5MM X230MM

7518472

$11,54 Unit Price incl. VAT

16

BUSHING-CONTROL ARM;1.285

5436832

5439874

$4,19 Unit Price incl. VAT

Find the detailed REAR SUSPENSION POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
