1
Engine displacement
800
2
Year
2016
3
Trim
800 AXYS SKS 155
4
Parts Catalog
OIL BOTTLE ASM.
5
Parts Diagram
Parts Catalog
CHASSIS, BULKHEAD ASM.
by
OIL PUMP ASM.
OIL BOTTLE ASM.
1
2
3
4
5
6
7
8
1
VENTED OIL CAP CUSTOM COLOR
1240094
1244736
$68,24 Unit Price incl. VAT
2
OIL BOTTLE ASSEMBLY
2521361
2522533
$95,98 Unit Price incl. VAT
3
DECAL-CLTCH WARN/BELT RMVL/OIL
7181093
Not Available
4
FLANGED GROMMET; .36 X .56 X 1.06
7052362
$13,64 Unit Price incl. VAT
5
FITTING-1/4 STRAIGHT W/FILTER
7052593
7055634
$36,53 Unit Price incl. VAT
6
OIL LEVEL SWITCH; NO CONTACT
4014699
$125,99 Unit Price incl. VAT
7
SCR-TXTH-M6X1.0X20 T40 ZPB
7519112
$6,29 Unit Price incl. VAT
8
WSHR-6.4X18.0X1.6 ZC
7556565
$4,19 Unit Price incl. VAT

Find the detailed OIL BOTTLE ASM. POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
