1
Engine displacement
500
2
Year
2002
3
Trim
500 WIDETRAK LX
4
Parts Catalog
COOLING SYSTEM
5
Parts Diagram
Parts Catalog
DRIVE CLUTCH
by
SHIFT LINKAGE
COOLING SYSTEM
1
2
3
4
5
6
7
8
8
8
8
9
10
10
10
10
11
11
12
12
13
14
14
15
16
17
18
19
20
21
22
23
24
24
25
25
25
25
25
26
26
26
27
28
29
1
2
3
4
5
6
7
8
8
8
8
9
10
10
10
10
11
11
12
12
13
14
14
15
16
17
18
19
20
21
22
23
24
24
25
25
25
25
25
26
26
26
27
28
29
1
BOLT
7512276
$9,44 Unit Price incl. VAT
2
WASHER WROUGHT
7558302
$3,14 Unit Price incl. VAT
3
OVERFLOW CAP
5430743
$10,49 Unit Price incl. VAT
4
PLUG
5431096
$3,66 Unit Price incl. VAT
5
GASKET
5810279
$4,19 Unit Price incl. VAT
6
NUT
7670096
$3,14 Unit Price incl. VAT
7
BOTTLE O FLOW W/FITTING
5431733
9999999
Not Available
8
RIVET
7661637
$2,09 Unit Price incl. VAT
9
CENTER COOLING EXTERNAL
2511187
9999999
Not Available
10
SPRINGBAND CLAMP; 27/12; GREEN
7080841
$13,64 Unit Price incl. VAT
11
SPRINGBAND CLAMP; 35/12
7080844
$19,94 Unit Price incl. VAT
12
COOLER; SIDE; RIGHT
2511258
9999999
Not Available
12
COOLER LH SIDE(XTRA 10)
2511257
9999999
Not Available
13
GUARD COOL.EXT.
5240555
9999999
Not Available
14
TUBING CONVOL 8 X1 IN
5411396
9999999
Not Available
15
HOSE CROSSOVER SHORT
5410558
9999999
Not Available
16
HOSE CROSSOVER
5410557
9999999
Not Available
17
HOSE CLOSEOFF OUT ENG.
5411382
9999999
Not Available
18
BRKT OILTANK COINED
5241334
9999999
Not Available
19
CLAMP SPRINGBAND 29/12 BLK
7080842
$13,64 Unit Price incl. VAT
20
HOSE FILLER OUT RH.EXT.
5411381
9999999
Not Available
21
HOSE ENG.OUT/FILLER
5411010
9999999
Not Available
22
REMOTE COOLANT FILTER
5433364
$73,49 Unit Price incl. VAT
23
CAP PRESS
2511256
9999999
Not Available
24
TUBING CONVOL 1 X2.5
5521242
9999999
Not Available
25
HOSE CLAMP
7080307
$1,56 Unit Price incl. VAT
26
FUEL LINE; 1/4 ID
84500031525
Not Available
27
CHECK VALVE
7052038
$20,99 Unit Price incl. VAT
28
FILTER COOLANT LGE.
2530024
9999999
Not Available
29
ROSEBUD CLIP
4020139
$9,44 Unit Price incl. VAT

Find the detailed COOLING SYSTEM POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
