1
Engine displacement
autre
2
Year
2017
3
Trim
GEM (R24) - L17G2/4/6/EURO ALL OPTIONS
4
Parts Catalog
CONTROLS, PEDALS AND PARK BRAKE
5
Parts Diagram
Parts Catalog
BRAKES, DRUM
by
ELECTRICAL, 6.5KW MOTOR
CONTROLS, PEDALS AND PARK BRAKE
10
11
12
13
14
15
16
17
18
18
19
20
21
22
23
24
25
1
WELD-BRAKE PEDALM.BLK
1021445458
Not Available
2
WELD-MOUNT ACCELERATOR BLK
1021453458
Not Available
3
WELD-SUPPORT BRAKE BLK
1021616458
Not Available
4
LEVER-BRAKE
1912587
9999999
Not Available
5
ASM-BRAKE PARK LEVER
1912767
9999999
Not Available
6
ASM-BRAKE PARK HANDLE
1912586
9999999
Not Available
7
SWITCH-PARKING BRAKE
2413166
9999999
Not Available
8
CABLE-BRAKE PARK LEVER
7082125
9999999
Not Available
9
PIN-M8
7662258
9999999
Not Available
10
PIN-COTTER
7662259
9999999
Not Available
11
ELECTRONIC THROTTLE PEDAL
4014989
4082743
$377,99 Unit Price incl. VAT
12
BRAKE PEDAL BUSHING TUBE
5335739
$19,94 Unit Price incl. VAT
13
PEDAL PIVOT BUSHING
5433189
$7,34 Unit Price incl. VAT
14
BOLT-M8X1.25X25 HXFLG-OLIVE D
7518514
$3,14 Unit Price incl. VAT
15
HEX HEAD FLANGE SCREW; 6 MM X 16 MM
7518591
$6,29 Unit Price incl. VAT
16
SCR-M8X1.25X75 8.8 HX/FL ZOD
7518955
$6,29 Unit Price incl. VAT
17
HEX FLANGE SCREW; 8 MM X 1.25 MM X 35 MM
7519052
$3,14 Unit Price incl. VAT
18
NYLOC OLIVE NUT; 8 MM X 1.25 MM
7547332
$7,34 Unit Price incl. VAT
19
HEX FLANGE NUT; 6 MM X 1.0 MM
7547453
$7,34 Unit Price incl. VAT
20
NUT-RIVNUT M8X1.25
7547788
9999999
Not Available
21
WASHER
7555954
$9,44 Unit Price incl. VAT
22
SPACER-BRAKE PARK
7556923
9999999
Not Available
23
CLIP PIN; 14 MM
7661140
$2,09 Unit Price incl. VAT
24
CLEVIS PIN; 1/4 X 3/4
7661843
$4,19 Unit Price incl. VAT
25
CLIP J
7080884
$7,34 Unit Price incl. VAT

Find the detailed CONTROLS, PEDALS AND PARK BRAKE POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
