SUSPENSION, FRONT SHOCK for POLARIS SCRAMBLER XP 1000 from 2017

SUSPENSION, FRONT SHOCK

1

REMOTE RESEVOIR SHOCK; FRONT

7044135

9999999

Not Available

2

BODY (207-41-084)

1500933

9999999

Not Available

3

SHAFT 7.95 TLG (229-28-011)

1500934

9999999

Not Available

4

EYELET; SHAFT

1500889

9999999

Not Available

5

BEARING CAP ASSEMBLY

1500924

9999999

Not Available

6

BEARING ASSEMBLY

1500925

$178,49 Unit Price incl. VAT

7

GUIDE SPRING (234-27-000)

1500930

$83,99 Unit Price incl. VAT

8

NUT LOCK

1500016

$23,09 Unit Price incl. VAT

9

RESERVOIR 4.5 TLG (227-34-045)

1500926

9999999

Not Available

10

END CAP ASSEMBLY

1500765

9999999

Not Available

11

PISTON ASSEMBLY

1500781

9999999

Not Available

12

ASM. DAMP; ADJ LSC 815-04-045

1501006

9999999

Not Available

13

BUMPER

1500902

$62,99 Unit Price incl. VAT

14

WASHER CUSTOM

1500896

$36,74 Unit Price incl. VAT

15

RING; PRELOAD (234-00-325)

1500928

9999999

Not Available

16

RING PRELOAD BACK-UP

1500895

$73,49 Unit Price incl. VAT

17

EYELET; BUSHING

1500103

$16,79 Unit Price incl. VAT

18

SLEEVE; .57 X .81 X 1.15

1500497

$68,24 Unit Price incl. VAT

19

BUSHING .35ILG .63TLG

1500307

$13,64 Unit Price incl. VAT

20

SLEEVE

1500929

9999999

Not Available

21

RING-RETAINING WIRE

1500097

$9,44 Unit Price incl. VAT

22

RING RETAINING

1500236

$17,84 Unit Price incl. VAT

23

DECAL; RES. (024-00-182)

1500931

9999999

Not Available

24

ASM.; BODY CAP (804-00-130)

1500904

9999999

Not Available

Find the detailed SUSPENSION, FRONT SHOCK POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
