1
Engine displacement
autre
2
Year
1992
3
Trim
TRAIL BOSS 4X4 - W928127
4
Parts Catalog
ENGINE MOUNTS EXHAUST 250 4X4 / W928127 (4922872287A009)
5
Parts Diagram
Parts Catalog
FRAME ASSEMBLY W/ RACKS 250 4X4 / W928127 (4922872287A007)
by
CENTER TIGHTENER ASSEMBLY P/N 1380023 250 4X4 / W928127 (4922872287B001)
ENGINE MOUNTS EXHAUST 250 4X4 / W928127 (4922872287A009)
1
2
3
4
5
6
7
8
9
10
11
12
13
13
13
14
14
15
16
17
18
19
1
2
3
4
5
6
7
8
9
10
11
12
13
13
13
14
14
15
16
17
18
19
1
1
2
3
4
5
6
6
6
6
6
6
7
7
7
7
7
7
8
9
10
11
12
13
14
15
16
17
18
18
19
20
20
21
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
38
38
39
40
41
42
43
44
44
44
44
45
46
47
2
49
1
POST STEERING ASM. (Incl. 10 12)
1843043
Not Available
1
MOUNT MOTOR
3110026
9999999
Not Available
2
NYLOK NUT
7542324
$1,56 Unit Price incl. VAT
2
MOTOR MOUNT INSULATOR
5430802
9999999
Not Available
3
FLAT WASHER
7558402
$1,56 Unit Price incl. VAT
3
BOLT
7515321
9999999
Not Available
4
BRKT UP.STRG.BUSH BLK.
5222999067
Not Available
4
SPRING LOCK WASHER
7552901
$2,09 Unit Price incl. VAT
5
BUSHING STRG.CONSOLE
5431572
5433416
$16,79 Unit Price incl. VAT
5
MOUNT ENG.TOP
5220471067
Not Available
6
BUSHING STRG.CONSOLE
5431573
5433415
$16,79 Unit Price incl. VAT
6
WASHER
7555801
$7,34 Unit Price incl. VAT
7
NUT LOCK
7542403
9999999
Not Available
7
ZERK FITTING
7080510
$10,49 Unit Price incl. VAT
8
BRKT; IGN. PANEL
5220965067
Not Available
8
BOLT
7512566
9999999
Not Available
9
SCREW(10)
7512310
$4,19 Unit Price incl. VAT
9
WASHER LOCK
7575202
$9,44 Unit Price incl. VAT
10
WASHER
5210748
$7,34 Unit Price incl. VAT
10
FITTING LUBRICATION THREADED(1
7080433
$2,09 Unit Price incl. VAT
11
BUSHING
5430261
$13,64 Unit Price incl. VAT
11
PIN; COTTER
7661633
9999999
Not Available
12
CLUTCH; BASIC
1321497
1321976
$1 081,49 Unit Price incl. VAT
12
PLUG GREASE STRG.
5431574
9999999
Not Available
13
SEAL ENG./CLUTCH
5410411
9999999
Not Available
13
BUSHING
7555781
9999999
Not Available
14
O-RING
5410772
9999999
Not Available
14
NUT
3080285
9999999
Not Available
15
LOCK WASHER
3080530
9999999
Not Available
15
STEERING BUSHING LOWER
5431570
9999999
Not Available
16
SCREW SPEC.
5020601
9999999
Not Available
16
MANIFOLD BLK.
1260543029
Not Available
17
ENG.EC25PF-05(ATV) [No Longer Available]
1211460
Not Available
17
SPACER STRG.POST
5431571
9999999
Not Available
18
NUT HEX SLOTTED
7543203
9999999
Not Available
18
CLAMP
7080136
9999999
Not Available
19
MONOBOLT RIVET
7661632
9999999
Not Available
19
CLUTCH INTAKE BOOT
5410421
9999999
Not Available
20
SCREW
7512490
$7,34 Unit Price incl. VAT
21
WASHER SPRINGLOCK
7553001
7552603
$1,56 Unit Price incl. VAT
22
PLATE FR.MTR.MT.
5220881067
Not Available
23
SPRING
7042029
$10,49 Unit Price incl. VAT
24
HEADPIPE WELD.
1260540029
Not Available
25
SPRING; EXHAUST
7042031
7041687
$12,59 Unit Price incl. VAT
26
MUFFLER/ARRESTER WELD.
1260535029
Not Available
27
SHIELD MUFFLER BLACK Substituted by 5220671-067
5222117
Not Available
28
ASM. BOLT&WASHER
3083729
9999999
Not Available
29
ASM. BOLT AND WASHER
3083730
9999999
Not Available
30
COLLAR
3083732
9999999
Not Available
31
MOUNTING RUBBER
3083731
9999999
Not Available
32
BOLT
7512666
$4,19 Unit Price incl. VAT
33
BOLT
7515316
$4,19 Unit Price incl. VAT
34
WASHER RUBBER
5410436
9999999
Not Available
35
MOUNT REAR
5220757067
Not Available
36
MOUNT ENGINE
3110028
9999999
Not Available
37
CHECKVALVE VENT
7052047
9999999
Not Available
38
LINE VENT (38.0 )
5521087
8360009-600
$83,99 Unit Price incl. VAT
39
BR8ES SPARK PLUG; NGK(4)
3070156
$7,34 Unit Price incl. VAT
40
INSUL.CABLE SOL.
5410346
9999999
Not Available
41
CABLE GROUND/ENG.
4010067
9999999
Not Available
42
VIBRATION DAMPENER
5410467
9999999
Not Available
43
SUPPORT FENDER; REAR; MEDIUM GLOSS BLACK
5220902067
Not Available
44
BRKT LH SUPPORT RACK
5220899067
Not Available
44
BRKT RH SUPPORT RACK
5220901067
Not Available
45
DAMPENER
5410241
5412508
$9,44 Unit Price incl. VAT
46
BUSHING
5010192
$12,59 Unit Price incl. VAT
47
WASHER
7555716
$3,14 Unit Price incl. VAT
48
NYLOK NUT
7542324
$1,56 Unit Price incl. VAT
49
WASHER
7555726
$3,14 Unit Price incl. VAT

Find the detailed ENGINE MOUNTS EXHAUST 250 4X4 / W928127 (4922872287A009) POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
