1
Engine displacement
700
2
Year
2007
3
Trim
RANGER 4X4 700 EFI/LE - R07RH68AD/AG/AH/AK/AL/AO/AP/AW
4
Parts Catalog
REAR WHEEL
5
Parts Diagram
Parts Catalog
FRONT WHEEL
by
WINCH
REAR WHEEL
1
2
3
3
4
4
5
5
5
5
5
5
5
5
6
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
6
7
8
9
10
11
12
13
14
15
1
BOLT
7515522
$7,34 Unit Price incl. VAT
2
REAR BRAKE DISC 8.625 IN.
5248250
$141,74 Unit Price incl. VAT
3
PRESS FIT STUD
7518378
$3,14 Unit Price incl. VAT
3
STUD 3/8-24 X 1.12
7515513
9999999
Not Available
4
REAR WHEEL HUB ASSEMBLY MACHINED
5135113
5143629
$157,49 Unit Price incl. VAT
4
REAR WHEEL HUB; MEDIUM GLOSS BLACK
5135113067
Not Available
5
WELD-RIM 14X8 REAR
1521127
9999999
Not Available
5
REAR RIM GS BLK
1520797067
Not Available
5
RIM REAR 12X8 10GA NBU CAMO
1520797455
Not Available
5
RIM-REAR 12X8 CAST ALUM
1520899
9999999
Not Available
6
TIRE-REAR 26X11R12__UU0
5412687
5419043
$306,38 Unit Price incl. VAT
6
TIRE-REAR 26X12R14
5413214
9999999
Not Available
7
WASHER .385 X 88 X .075
7556242
$4,19 Unit Price incl. VAT
8
FLANGED NUT LOCK(10)
7542459
$3,14 Unit Price incl. VAT
9
CONE WASHER
7555796
$14,69 Unit Price incl. VAT
10
CASTLE NUT
7543005
9999999
Not Available
11
COVER DUST HUB
5411164
5413427
$52,49 Unit Price incl. VAT
12
COTTER PIN
7661404
$9,44 Unit Price incl. VAT
13
RIM VALVE
1525017
$12,59 Unit Price incl. VAT
14
WHEEL NUT
7547309
$6,81 Unit Price incl. VAT
15
CENTER CAP; EMBOSSED STAR LOGO
1521128
$35,69 Unit Price incl. VAT

Find the detailed REAR WHEEL POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
