SWING ARM WELDMENT (MIDDLE) (4917741774026A) for POLARIS BIG BOSS 4X6

MIDDLE DRIVE ASSEMBLY ASSEMBLY (4917741774025A)

REAR SWING ARM SHOCK UPDATED 5/90 (4917741774027A)

NYLOCK NUT

7542439

$2,09 Unit Price incl. VAT

SCREW

7515415

9999999

Not Available

TOP RETAINER

5220225

$19,94 Unit Price incl. VAT

COMPRESSION SPRING; REAR; GS BLK

7041204067

Not Available

SHOCK

7041220

9999999

Not Available

ADAPTER SPRING SEAT

5630351

9999999

Not Available

OIL SEAL

3610016

9999999

Not Available

WASHER

7555779

9999999

Not Available

BUSHING SWING ARM(10)

5010255

9999999

Not Available

ROLLERCHAIN GUIDE

5431003

9999999

Not Available

NUT CROWN LOCK

7542601

9999999

Not Available

BOLT LOCK PLATE

5220958

9999999

Not Available

BOLT; SHOULDER

7512704

9999999

Not Available

BUSHING MACH.(10)

7555752

9999999

Not Available

BEARING

3576507

9999999

Not Available

BUSHING SWING ARM

5010237

9999999

Not Available

ARM SWING WELD. Substituted by 1580035-067

1580035

Not Available

RIVET

7621433

$2,09 Unit Price incl. VAT

GUIDE CHAIN

5431017

9999999

Not Available

FLANGED SCREW

7515304

9999999

Not Available

BUSHING

5332828

9999999

Not Available

GUARD CHAIN(MODIFIED)

5430952

9999999

Not Available

PIVOT SWING ARM Substituted by 5130696

5610111

Not Available

GUARD RACK Substituted by 1040183-132

1040183

Not Available

BRKT SWING ARM EXT.

1580046

Not Available

BRKT SWG.ARM EXT. Substituted by 1580037-067

1580037

Not Available

FLANGE NUT

7542321

$2,09 Unit Price incl. VAT

NUT FLANGE

7542522

$10,49 Unit Price incl. VAT

BOLT

7512520

$9,44 Unit Price incl. VAT

FITTING LUBE.W/BALL CK.(10)

7080306

$5,76 Unit Price incl. VAT

BOLT

7512569

9999999

Not Available

HOUSING AXLE

5130663

9999999

Not Available

BOLT SHOULDER

7512703

Not Available

MT; RACK GUARD

5222221

5222221-132

Not Available

GUARD F.CHAIN

5431102

9999999

Not Available

SCREW

7512252

9999999

Not Available

FLAT WASHER

7558301

$2,09 Unit Price incl. VAT

BRKT CHAIN GUARD

5222220

5222220-067

Not Available

RIVET(10)

7621301

9999999

Not Available

RIVET BURR(50)

7555756

9999999

Not Available

BOLT

7512325

$4,19 Unit Price incl. VAT

SPRING LOCK WASHER

7552901

$2,09 Unit Price incl. VAT

HEX NUT

7542301

$3,14 Unit Price incl. VAT

FITTING LUBE

7080342

7080438

$19,94 Unit Price incl. VAT

HOLDER

5130712

9999999

Not Available

Find the detailed SWING ARM WELDMENT (MIDDLE) (4917741774026A) POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
