1
Engine displacement
1000
2
Year
2018
3
Trim
RANGER XP 1000 EPS NORTHSTAR HVAC EDITION
4
Parts Catalog
AIR CONDITIONING DUCTING
5
Parts Diagram
Parts Catalog
REAR CLOSEOFF AND FENDERS
by
AIR CONDITIONING ROUTINGS
AIR CONDITIONING DUCTING
1
2
3
4
5
6
7
8
9
10
11
11
12
13
14
15
16
17
18
19
20
1
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
2
DASH DUCTING ASSEMBLY; RIGHT
2636685
$257,24 Unit Price incl. VAT
3
DUCTING ASSEMBLY; DASH; CENTER; LEFT
2636686
$178,49 Unit Price incl. VAT
4
DASH DUCTING ASSEMBLY; LEFT
2636684
$257,24 Unit Price incl. VAT
5
CENTER DASH DUCTING ASSEMBLY; RIGHT
2636687
$178,49 Unit Price incl. VAT
6
HVAC AIR DISTRIBUTOR MANIFOLD
5453899
$68,24 Unit Price incl. VAT
7
BRKT-MOUNT HVAC UNIT BLK
5263841329
Not Available
8
FRESH AIR HOSE
5416208
$68,24 Unit Price incl. VAT
9
AIR BOX FILTER ASSEMBLY
1262218
$38,42 Unit Price incl. VAT
10
FILTER SUPPORT
5453415
$52,49 Unit Price incl. VAT
11
SCREW
7512026
$2,09 Unit Price incl. VAT
12
NYLOC OLIVE NUT; 8 MM X 1.25 MM
7547332
$7,34 Unit Price incl. VAT
13
WASHER
7555716
$3,14 Unit Price incl. VAT
14
ROUND VENT
5452877
$62,99 Unit Price incl. VAT
15
DEFROST VENT
5453900
$68,24 Unit Price incl. VAT
16
BOLT M6 X 1.0 X 20
7518529
$2,09 Unit Price incl. VAT
17
BAND CLAMP; NARROW
7080707
$5,76 Unit Price incl. VAT
18
TIE CABLE; 14 IN
7080761
$5,24 Unit Price incl. VAT
19
DUCT-Y HOSE HTR XOVR
5452894
$104,99 Unit Price incl. VAT
20
NUT-M6X1.0 FLG-NYLOC-OLIVE D
7547339
$2,09 Unit Price incl. VAT

Find the detailed AIR CONDITIONING DUCTING POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
