1
Engine displacement
600
2
Year
2016
3
Trim
600 WIDETRAK IQ
4
Parts Catalog
SEAT RISER ASM.
5
Parts Diagram
Parts Catalog
SEAT ASM.
by
SIDE PANELSS
SEAT RISER ASM.
1
2
3
3
4
4
5
6
7
8
9
10
11
12
12
13
1
2
3
4
4
5
6
7
8
9
10
11
12
13
1
ASM-SEAT RISER;FS WIDETRAK;BLK
1016461458
Not Available
2
NYLOK NUT
7542122
$2,09 Unit Price incl. VAT
3
NUTSERT HEX
7547069
$7,34 Unit Price incl. VAT
4
SEAL SEAT RISER
5410562
9999999
Not Available
5
SEAL SHORT SEAT RISER
5410563
9999999
Not Available
6
HINGE-FLAT 3X2
7081525
9999999
Not Available
7
SCREW
7517230
$2,09 Unit Price incl. VAT
8
RIVET
7621433
$2,09 Unit Price incl. VAT
9
SCREW .75
7517441
$4,19 Unit Price incl. VAT
10
PROTECTOR-RISER
5413471
9999999
Not Available
11
BOLT
7515203
$7,34 Unit Price incl. VAT
12
RIVET
7661637
$2,09 Unit Price incl. VAT
12
BRKT-SEAT LATCH;BLK
5252159329
Not Available
13
NYLOK FLANGED NUT
7542153
$3,14 Unit Price incl. VAT

Find the detailed SEAT RISER ASM. POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
