STEERING POST ASM. for POLARIS SPORTSMAN 400 HO 4X4 - A09LH46AQ/AX/AZ from 2009

STEERING, HANDLEBAR CONTROLS

SUSPENSION, A-ARM AND STRUT MOUNTING

STEERING POST ASM.

1

ASM-TIE ROD339.2 LONG

1822955

9999999

Not Available

2

SEAL BOOT ROD END 1/2 IN

5411291

5412928

$20,99 Unit Price incl. VAT

3

ROD END; RIGHT; 10 MM; 12 MM X 1.5 MM

7061134

$115,49 Unit Price incl. VAT

4

NUT-M12X1.5 RH FULL JAM

7547358

$8,39 Unit Price incl. VAT

5

NUT-NUT12X1.5 LH FULL JAM

7547357

9999999

Not Available

6

BOOT SEAL ROD END 10MM

5411920

5412929

$20,99 Unit Price incl. VAT

7

ROD END; LEFT; 10 MM; 12 MM X 1.5 MM

7061135

$115,49 Unit Price incl. VAT

8

ROD-TIE 1/2-M12 X 1.5

5134603

9999999

Not Available

9

COTTER PIN

7661203

$2,09 Unit Price incl. VAT

10

HEX FLANGE NUT; 10 MM X 1.5 MM

7547313

$2,09 Unit Price incl. VAT

11

BOLT-M10X1.5X55 HX HD FLG

7518605

9999999

Not Available

12

BOLT-M10X1.5X60 HXHDFLG

7518682

9999999

Not Available

13

RETAINER-TIE ROD

5248353

9999999

Not Available

14

WASHER

7556099

$3,14 Unit Price incl. VAT

15

ASM-STEER POSTHAWK4X4 RADRIV

1015959

9999999

Not Available

16

BOLT-M8X1.25X20 CARRIAGE

7518479

$7,34 Unit Price incl. VAT

17

BRKT-UPPER BUSHING

5246732

5257028

$62,99 Unit Price incl. VAT

18

BUSHING-UPPER 1 IN

5433866

5439731

$12,59 Unit Price incl. VAT

19

BOLT-M8X1.25X25 HXHD W/PATCH

7518471

9999999

Not Available

20

NUT-M8X1.25 HXFLG NYLON INS

7547317

7548028

$5,24 Unit Price incl. VAT

Find the detailed STEERING POST ASM. POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
