1
Engine displacement
1000
2
Year
2020
3
Trim
RZR XP 4 1000
4
Parts Catalog
REAR SUSPENSION SHOCK INTERNALS
5
Parts Diagram
Parts Catalog
FRONT SUSPENSION SHOCK MOUNTING
by
STABILIZER BAR, REAR
REAR SUSPENSION SHOCK INTERNALS
-
1
2
3
4
5
6
6
7
8
8
9
10
11
12
13
14
14
15
16
17
18
19
19
20
21
21
22
23
12
25
26
27
28
29
30
31
31
32
-
SHOCK; REAR
7044899
9999999
Not Available
1
SHAFT LOOP
1800555
$440,99 Unit Price incl. VAT
2
NUT-SPRING 2.5 CLR 1425124-AC
1800836
$162,74 Unit Price incl. VAT
3
ASM-PISTON RES. 2.5 0925205
1800752
$272,99 Unit Price incl. VAT
4
RES-2.5X9.5L CLR 1625027
1800854
$561,74 Unit Price incl. VAT
5
SHAFT CHR NEEDLE 7/8 1425122
1800713
$262,49 Unit Price incl. VAT
6
BUMPER
1800201
1800593
$125,99 Unit Price incl. VAT
7
O-RING
1800613
$20,99 Unit Price incl. VAT
8
O-RING
1800508
$10,49 Unit Price incl. VAT
9
O-RING
1800500
$3,66 Unit Price incl. VAT
10
RETAINING RING
1800482
$20,99 Unit Price incl. VAT
11
NUT 7/16 NYLOCK (1425112)
1800638
$9,44 Unit Price incl. VAT
12
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
13
CAP WIPER; 2.5 IN X .88 IN
1800855
$89,24 Unit Price incl. VAT
14
BRIDGE-2.5 ADJ;CLR 1625034-AC
1800841
$482,99 Unit Price incl. VAT
15
JAM NUT-2.5 1325445-AC
1800842
$68,24 Unit Price incl. VAT
16
MOUNT-RES 2.5IN (WER-1125335)
1800488
$167,99 Unit Price incl. VAT
17
SCREW-1/4-20X.50 1200338
1800754
$6,29 Unit Price incl. VAT
18
SPACER 2.037L 1425106
1800657
$52,49 Unit Price incl. VAT
19
RETAINING RING; 2.5 IN
1800847
$41,99 Unit Price incl. VAT
20
WIRE RING 2.48X.062 1525023
1800846
$15,74 Unit Price incl. VAT
21
O-RING
1800497
$10,49 Unit Price incl. VAT
22
O-RING
1800502
$3,66 Unit Price incl. VAT
23
WIPER; .875SHFT (1425107)
1800641
$68,24 Unit Price incl. VAT
24
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
25
ASM-SEAL HD 2.5X.88PI 1625024
1800856
$204,74 Unit Price incl. VAT
26
ASM-END CAP 2.5 1625028-AC
1800844
$241,49 Unit Price incl. VAT
27
ASM-CHECK VALVE 1145712-4
1800848
$115,49 Unit Price incl. VAT
28
ASM-SS RET. NUT;GLD 1125697-AG
1800857
$204,74 Unit Price incl. VAT
29
O-RING
1800503
$3,14 Unit Price incl. VAT
30
O-RING
1800810
$6,81 Unit Price incl. VAT
31
BEARING; HCOM9T-12MM 1600131
1800880
$80,84 Unit Price incl. VAT
32
SPRING RETAINER; 2.5 IN
1501211
$83,99 Unit Price incl. VAT

Find the detailed REAR SUSPENSION SHOCK INTERNALS POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
