1
Engine displacement
autre
2
Year
1996
3
Trim
MAGNUM 4X4 - W968144
4
Parts Catalog
CONTROLS
5
Parts Diagram
Parts Catalog
CONTROLS
by
SWING ARM SHOCK MAGNUM 4X4 W968144 AND SWEDISH MAGNUM 4X4 S968144 (4936053605B012)
CONTROLS
-
-
1
2
3
4
5
6
7
8
8
9
10
11
11
11
11
11
11
11
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
35
36
37
38
39
40
-
-
1
2
3
4
5
6
7
8
8
9
10
11
11
11
11
11
11
11
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
35
36
37
38
39
40
-
MASTER CYL.ASM.
2050062
2050073
$456,74 Unit Price incl. VAT
-
MASTER CYL. ASM. (See Pg. A28)
2050063
Not Available
1
SCREW W/WASHER
7512050
9999999
Not Available
2
COVER MASTER CYL.
5630338
9999999
Not Available
3
MASTER CYLINDER GASKET
5410527
9999999
Not Available
4
BAFFLE MASTER CYL.
1930673
9999999
Not Available
5
WASHER; BAFFLE
1930662
9999999
Not Available
6
BOLT BRAKE LEVER
7512287
9999999
Not Available
7
PINBRAKELEVER ROLLER
7661627
9999999
Not Available
8
ROLLER BRAKE LEVER
5020598
9999999
Not Available
9
CLAMP MASTER CYL.
5630342
9999999
Not Available
10
BOLT SOCKET HEAD
7512290
$9,44 Unit Price incl. VAT
11
HOUSING MASTER CYL.SCAN (Euro)
5130961
Not Available
11
MASTER CYLINDER HOUSING
5130955
9999999
Not Available
12
GLASS SIGHT MASTER CYL.
1930710
Not Available
13
SEAL SIGHT GLASS
1930660
9999999
Not Available
14
WASHER
7555708
9999999
Not Available
15
SPRING; MASTERCYL.
7041311
9999999
Not Available
16
SEAL CUP(ATV)
5410994
9999999
Not Available
17
MASTER CYLINDER PISTON
5020671
9999999
Not Available
18
O-RING
5410163
$3,14 Unit Price incl. VAT
19
OIL SEAL
3610022
9999999
Not Available
20
RING RETAINING
7710425
9999999
Not Available
21
SCREW
7511876
9999999
Not Available
22
RIVET BURR(50)
7555756
9999999
Not Available
23
BUSHING PK.BRAKE LEVER
5020670
9999999
Not Available
24
LEVER PARKBRAKE ATV
5240865
9999999
Not Available
25
NUT
7542124
7542122
$2,09 Unit Price incl. VAT
26
SPRING PK.BRAKE
7041229
9999999
Not Available
27
LEVER BRAKE(ATV)
5630455
9999999
Not Available
28
BUSHING BRAKE LEVER
5332931
9999999
Not Available
29
BRAKE LINE
1930748
$167,99 Unit Price incl. VAT
30
STOPLIGHT SWITCH
4110164
2890637
$325,49 Unit Price incl. VAT
31
LINEBRAKEREAR
1930751
9999999
Not Available
32
RIVET
7621462
$2,09 Unit Price incl. VAT
33
CLAMP NYLON CABLE
7080539
$9,44 Unit Price incl. VAT
34
BRAKE LINE
1930752
9999999
Not Available
35
STRAP BLK
7080272
9999999
Not Available
36
CONDUIT; 30 CM.
836003130
Not Available
37
SCREW
7512027
$2,09 Unit Price incl. VAT
38
CONDUIT; 38 CM.
836003138
Not Available
39
BRAKE LINE WITH FITTINGS; FRONT; RIGHT
1930753
9999999
Not Available
40
FITTING CROSS INVERT.FLARE
7052103
9999999
Not Available

Find the detailed CONTROLS POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
