1
Engine displacement
autre
2
Year
1996
3
Trim
MAGNUM 4X4 - W968144
4
Parts Catalog
ENGINE MOUNTING MAGNUM 4X4 W968144 AND SWEDISH MAGNUM 4X4 S968144 (4936053605A008)
5
Parts Diagram
Parts Catalog
BUMPER / RACKS MOUNTING MAGNUM 4X4 W968144 AND SWEDISH MAGNUM 4X4 S968144 (4936053605A007)
by
COOLING SYSTEM MAGNUM 4X4 W968144 AND SWEDISH MAGNUM 4X4 S968144 (4936053605A009)
ENGINE MOUNTING MAGNUM 4X4 W968144 AND SWEDISH MAGNUM 4X4 S968144 (4936053605A008)
1
2
2
3
4
5
6
7
8
8
9
9
9
10
10
11
12
12
13
14
15
16
12
18
18
18
18
19
20
21
22
23
24
25
26
27
28
29
12
31
32
33
34
34
35
12
12
38
12
40
12
42
42
1
2
2
3
4
5
6
7
8
8
9
9
9
10
10
11
12
12
13
14
15
16
12
18
18
18
18
19
20
21
22
23
24
25
26
27
28
29
12
31
32
33
34
34
35
12
12
38
12
40
12
42
42
1
FLEXLOC NUT
7542411
$6,29 Unit Price incl. VAT
2
WASHER
7555801
$7,34 Unit Price incl. VAT
3
CABLE GROUND/ENG.
4010067
9999999
Not Available
4
MOUNT RUBBER TOP
3110044
3024012
$83,99 Unit Price incl. VAT
5
MOUNT ENG.TOP BLK.
5240328067
Not Available
6
SPRING LOCK WASHER
7552901
$2,09 Unit Price incl. VAT
7
BOLT
7512315
$9,44 Unit Price incl. VAT
8
HOSE CLAMP
7080307
$1,56 Unit Price incl. VAT
9
FUEL LINE; 600 CM
8450040600
Not Available
10
FUEL LINE; 1/4 ID
84500031525
Not Available
11
FITTING TEE
7052075
$17,84 Unit Price incl. VAT
12
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
13
MOUNT CARBURETOR
3110050
$19,94 Unit Price incl. VAT
14
BRKT CARB.MT.
5240609067
Not Available
15
WASHER
7552605
9999999
Not Available
16
HEX NUT
7542105
$7,34 Unit Price incl. VAT
17
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
18
HOSE CLAMP
7080003
$2,09 Unit Price incl. VAT
19
LINE FUEL 1/8 ID 600 CM.
8360009600
Not Available
20
MOUNT RUBBER REAR
3110045
9999999
Not Available
21
SCREW
7512490
$7,34 Unit Price incl. VAT
22
WASHER SPRINGLOCK
7553001
7552603
$1,56 Unit Price incl. VAT
23
MT. SEAL RETAINER BLK.
5211431067
Not Available
24
CLUTCH INTAKE BOOT
5410421
9999999
Not Available
25
NARROW BAND CLAMP
7080511
$9,44 Unit Price incl. VAT
26
BUSHING
5430261
$13,64 Unit Price incl. VAT
27
WASHER
5210748
$7,34 Unit Price incl. VAT
28
WASHER LOCK
7575202
$9,44 Unit Price incl. VAT
29
BOLT
7512566
9999999
Not Available
30
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
31
BRKT RETAINER SEAL BLK.
5240409067
Not Available
32
MOUNT RUBBER FRONT
3110046
9999999
Not Available
33
DECAL DRAIN RECOIL Substituted by 7078577
7075741
Not Available
34
HOSE CLAMP
7080614
$13,64 Unit Price incl. VAT
35
HOSEWATER305 CM.
8450050305
Not Available
36
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
37
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
38
MANIFOLD
1260720029
Not Available
39
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
40
ENG.(S.B.)EH42PL-01 [No Longer Available]
3085023
Not Available
41
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
Not Available
42
NUT LOCK
7542403
9999999
Not Available

Find the detailed ENGINE MOUNTING MAGNUM 4X4 W968144 AND SWEDISH MAGNUM 4X4 S968144 (4936053605A008) POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
