1
Engine displacement
500
2
Year
2009
3
Trim
SPORTSMAN 500 EFI TRACTOR - A09MN50ET
4
Parts Catalog
ENGINE, SPEED CONTROL
5
Parts Diagram
Parts Catalog
TURN SIGNALS, HORN and LICENSE PLATE LIGHT
by
HITCH
ENGINE, SPEED CONTROL
1
2
3
4
5
6
7
8
8
9
10
11
12
13
13
14
15
16
17
18
19
20
20
21
22
23
23
24
1
AIR CONTROL BODY ASSEMBLY
1240461
9999999
Not Available
2
ASM-BLOCK JET
3131700
3130504
$120,74 Unit Price incl. VAT
3
ASM-COVER
3131419
9999999
Not Available
4
DIAPHRAGM ASSEMBLY
3131443
$230,99 Unit Price incl. VAT
5
SPRING-COMP AIR CONTROL
3131699
9999999
Not Available
6
BODY-AIR CONTROL;(MACH)
5136684
9999999
Not Available
7
CAP-RUBBER 19/64 ID
5412334
9999999
Not Available
8
SCREW
7517505
$3,14 Unit Price incl. VAT
9
SMALL IN-LINE FILTER
2530009
$12,59 Unit Price incl. VAT
10
HALL EFFECT SENSOR; 32 IN
4011640
9999999
Not Available
11
HALL SENSOR CAP
5132382
9999999
Not Available
12
BRKT-SOLENOID BLK
5252767067
Not Available
13
FITTING-1/4 NPT TO 1/4 BARB90
7050000
$15,74 Unit Price incl. VAT
14
VALVE; 1/4 IN; AIR SOLENOID
7052379
9999999
Not Available
15
CABLE TIE
7080138
$5,24 Unit Price incl. VAT
16
SCREW(10)
7512018
$6,29 Unit Price incl. VAT
17
SCREW
7512208
9999999
Not Available
18
SCREW
7517386
$2,09 Unit Price incl. VAT
19
CONDUIT-145 CENTIMETERS
8360031145
Not Available
20
FUEL LINE; 1/4 ID
84500031525
Not Available
21
BRKT-SPEED SENSOR;E-COAT
5252619329
Not Available
22
BOOT-SPEED LIMITER TO EFI
5413613
9999999
Not Available
23
NARROW BAND CLAMP
7080511
$9,44 Unit Price incl. VAT
24
3/16 EPDM HOSE; 153 CM
8450113153
Not Available

Find the detailed ENGINE, SPEED CONTROL POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
