1
Engine displacement
autre
2
Year
1996
3
Trim
STORM - 0965782
4
Parts Catalog
DRIVE CLUTCH ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782 (4931593159C008)
5
Parts Diagram
Parts Catalog
FOX SHOCK
by
DRIVEN CLUTCH ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E96578 (4931593159C009)
DRIVE CLUTCH ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782 (4931593159C008)
1
BOLT
7512265
9999999
Not Available
2
SPRING LOCK WASHER
7552801
$3,14 Unit Price incl. VAT
3
BEARING COVER
3576510
$16,79 Unit Price incl. VAT
4
RETAINING RING COVER
7710417
$2,09 Unit Price incl. VAT
5
SPRING BLUE
7041080
$115,49 Unit Price incl. VAT
6
ROLLER PIN
5020422
$4,19 Unit Price incl. VAT
7
GUIDE BUTTON
5430445
$11,54 Unit Price incl. VAT
8
DRIVE CLUTCH KIT
2200387
$47,24 Unit Price incl. VAT
9
JAM NUT
5020425
$41,99 Unit Price incl. VAT
10
WASHER(10)
5430945
5438247
$3,14 Unit Price incl. VAT
11
ROLLER AND BUSHING ASSEMBLY
1321622
$62,99 Unit Price incl. VAT
12
SPACER .020
5210752
$3,14 Unit Price incl. VAT
12
SPACER .050
5210754
$6,29 Unit Price incl. VAT
12
SPACER .032
5210753
$4,19 Unit Price incl. VAT
13
CLUTCH WEIGHT; 10-56 (3)
1321684
$89,24 Unit Price incl. VAT
13
BUSHING WEIGHT ASSEMBLY(3)
1321587
$73,49 Unit Price incl. VAT
14
HARDENED WEIGHT PIN
7515105
$26,24 Unit Price incl. VAT
15
BEARING SLEEVE
3576502
$40,94 Unit Price incl. VAT
16
INSERT MOVEABLE
5010188
$13,64 Unit Price incl. VAT
17
FLEXLOC NUT(10)
7541906
$6,29 Unit Price incl. VAT
18
CLUTCH BASIC#54(DRIVE)
1321653
9999999
Not Available
18
CLUTCH UPDATE KIT
2200386
$314,99 Unit Price incl. VAT

Find the detailed DRIVE CLUTCH ASSEMBLY STORM 0965782, STORM SKS 0965582, EURO STORM E965782 (4931593159C008) POLARIS diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original POLARIS part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
